Schneider Electric HLL36070
SKU: HLL36070-R
Low stock
Estimated delivery: October 20th - October 22nd
Order for next-day shipment.
- Regular price
- $684.00
- Sale price
- $684.00
IAC Certified Refurbished
$684
Low stock
Description
The Schneider Electric (Square D) HLL36070 is a Powerpact molded case circuit breaker rated 70 A, 3-pole, 600 VAC, with an interrupting rating of 100 kA at 480 V. It uses a thermal magnetic trip unit with LI (Long-Time and Instantaneous) protection functions and Feed-Thru connection with line and load side lug terminals. It is UL listed, current limiting, and suitable for reverse-fed applications, with a non-interchangeable trip unit.
Breakers of this frame protect feeder and branch circuits in industrial and commercial distribution equipment, combining thermal overload protection with magnetic short-circuit protection in a compact molded case.
Technical Specifications
| Manufacturer | Schneider Electric (Square D) |
| Series | Powerpact |
| Type | Molded Case Circuit Breaker |
| Amperage | 70 A |
| Poles | 3 |
| Voltage | 600 VAC |
| Interrupting Rating | 100 kA @ 480 V |
| Trip Unit | Thermal Magnetic, LI (Long-Time and Instantaneous) |
| Connection | Feed-Thru, line and load side lugs |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $103/yr+3 yrs → 5 total $91/yr+5 yrs → 7 total $68/yrBEST VALUE+8 yrs → 10 total $51/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Schneider Electric (Square D) HLL36070 is a Powerpact molded case circuit breaker rated 70 A, 3-pole, 600 VAC, with an interrupting rating of 100 kA at 480 V. It uses a thermal magnetic trip unit with LI (Long-Time and Instantaneous) protection functions and Feed-Thru connection with line and load side lug terminals. It is UL listed, current limiting, and suitable for reverse-fed applications, with a non-interchangeable trip unit.
Breakers of this frame protect feeder and branch circuits in industrial and commercial distribution equipment, combining thermal overload protection with magnetic short-circuit protection in a compact molded case.
Technical Specifications
Manufacturer Schneider Electric (Square D) Series Powerpact Type Molded Case Circuit Breaker Amperage 70 A Poles 3 Voltage 600 VAC Interrupting Rating 100 kA @ 480 V Trip Unit Thermal Magnetic, LI (Long-Time and Instantaneous) Connection Feed-Thru, line and load side lugs -
