Siemens WLL2A308AHDCXGZXN
SKU: WLL2A308AHDCXGZXN-FS
This product is not available for online purchase.
Use the Request a quote to get the pricing
Description
Siemens WLL2A308AHDCXGZXN: a 800 A, 3-pole, 600 VAC WL Series insulated case circuit breaker. It provides 100kA@480V interrupting rating with solid state protection.
Factory specification: UL 1066, Interrupt rating (KA) 100 @ 254Vac-508Vac, 85 @ 635Vac, drawout, 800A, Frame size 2, Electronic trip Unit ETU745, LCD display (*) can be disabled, WLETU745 + WLLCD48 + WLGFM48, Auxiliary Switches Open/Close - 4a/4b, WLAS4, Shunt trip Voltage 120 AC/125 DC, WLST120, No UVR, Charge Motor Voltage 120AC/125DC Motor cut-off switch, WLELCMTR120S, Close coil operating voltage 120AC/125DC, power metering cable, Modbus 2, WLRCS120 + WLMETERP + WLCM16MD.
WLL2A308AHDCXGZXN Technical Specifications
| Manufacturer | Siemens |
| Series | WL Series |
| Type | Insulated Case Circuit Breaker |
| Connection | Draw-Out |
| Voltage | 600 V |
| Amperage | 800 A |
| Poles | 3 |
| Phase | 3 |
| AIC Rating | 100kA@480V |
| Protection | Solid State |
Industrial Automation Co. offers the WLL2A308AHDCXGZXN in New and IAC Certified Refurbished condition. Reach out to our sales team for availability, pricing, and lead time.
-
Buying Options
-
Description
Siemens WLL2A308AHDCXGZXN: a 800 A, 3-pole, 600 VAC WL Series insulated case circuit breaker. It provides 100kA@480V interrupting rating with solid state protection.
Factory specification: UL 1066, Interrupt rating (KA) 100 @ 254Vac-508Vac, 85 @ 635Vac, drawout, 800A, Frame size 2, Electronic trip Unit ETU745, LCD display (*) can be disabled, WLETU745 + WLLCD48 + WLGFM48, Auxiliary Switches Open/Close - 4a/4b, WLAS4, Shunt trip Voltage 120 AC/125 DC, WLST120, No UVR, Charge Motor Voltage 120AC/125DC Motor cut-off switch, WLELCMTR120S, Close coil operating voltage 120AC/125DC, power metering cable, Modbus 2, WLRCS120 + WLMETERP + WLCM16MD.
WLL2A308AHDCXGZXN Technical Specifications
Manufacturer Siemens Series WL Series Type Insulated Case Circuit Breaker Connection Draw-Out Voltage 600 V Amperage 800 A Poles 3 Phase 3 AIC Rating 100kA@480V Protection Solid State Industrial Automation Co. offers the WLL2A308AHDCXGZXN in New and IAC Certified Refurbished condition. Reach out to our sales team for availability, pricing, and lead time.
-
