Siemens ND62B120
SKU: ND62B120-FS
This product is not available for online purchase.
Use the Request a quote to get the pricing
Description
The Siemens ND62B120 is a Sentron Series molded case circuit breaker rated 1200 A, 2-pole, 600 VAC. It provides 50kA@480V interrupting rating with thermal magnetic protection.
Factory specification: 2P, 1PH, 1200A, 600V, 50kA@480V, standard interrupting capacity, 40ºC, Feed-Thru, complete with interchangeable trip unit and line & load side lug terminals, Thermal Magnetic molded case circuit breakers.
ND62B120 Technical Specifications
| Manufacturer | Siemens |
| Series | Sentron Series |
| Type | Molded Case Circuit Breaker |
| Connection | Feed-Thru |
| Voltage | 600 V |
| Amperage | 1200 A |
| Poles | 2 |
| Phase | 1 |
| AIC Rating | 50kA@480V |
| Protection | Thermal Magnetic |
| Functions | LI - Long-Time and Instantaneous |
| Frame Type | ND Frame |
The ND62B120 is available from Industrial Automation Co. in New and IAC Certified Refurbished condition. Contact our sales team for current availability, pricing, and lead time.
-
Buying Options
-
Description
The Siemens ND62B120 is a Sentron Series molded case circuit breaker rated 1200 A, 2-pole, 600 VAC. It provides 50kA@480V interrupting rating with thermal magnetic protection.
Factory specification: 2P, 1PH, 1200A, 600V, 50kA@480V, standard interrupting capacity, 40ºC, Feed-Thru, complete with interchangeable trip unit and line & load side lug terminals, Thermal Magnetic molded case circuit breakers.
ND62B120 Technical Specifications
Manufacturer Siemens Series Sentron Series Type Molded Case Circuit Breaker Connection Feed-Thru Voltage 600 V Amperage 1200 A Poles 2 Phase 1 AIC Rating 50kA@480V Protection Thermal Magnetic Functions LI - Long-Time and Instantaneous Frame Type ND Frame The ND62B120 is available from Industrial Automation Co. in New and IAC Certified Refurbished condition. Contact our sales team for current availability, pricing, and lead time.
-
