Siemens JXD63S400A
SKU: JXD63S400A-R
This product is not available for online purchase.
Use the Request a quote to get the pricing
Description
The Siemens JXD63S400A is a Sentron Series molded case circuit breaker rated 400 A, 3-pole, 600 VAC. It provides 35kA@480V interrupting rating with non-automatic protection.
Factory specification: 3P, 3PH, 400A, 600V, 35kA@480V, Bolt-On, lugs not included, NA - No Overcurrent Protection, Non-Automatic switch, molded case circuit breakers.
JXD63S400A Technical Specifications
| Manufacturer | Siemens |
| Series | Sentron Series |
| Type | Molded Case Circuit Breaker |
| Connection | Bolt-On |
| Voltage | 600 V |
| Amperage | 400 A |
| Poles | 3 |
| Phase | 3 |
| AIC Rating | 35kA@480V |
| Protection | Non-Automatic |
| Functions | NA - No Overcurrent Protection |
| Frame Type | JD Frame |
The JXD63S400A is available from Industrial Automation Co. in New and IAC Certified Refurbished condition. Contact our sales team for current availability, pricing, and lead time.
-
Buying Options
-
Description
The Siemens JXD63S400A is a Sentron Series molded case circuit breaker rated 400 A, 3-pole, 600 VAC. It provides 35kA@480V interrupting rating with non-automatic protection.
Factory specification: 3P, 3PH, 400A, 600V, 35kA@480V, Bolt-On, lugs not included, NA - No Overcurrent Protection, Non-Automatic switch, molded case circuit breakers.
JXD63S400A Technical Specifications
Manufacturer Siemens Series Sentron Series Type Molded Case Circuit Breaker Connection Bolt-On Voltage 600 V Amperage 400 A Poles 3 Phase 3 AIC Rating 35kA@480V Protection Non-Automatic Functions NA - No Overcurrent Protection Frame Type JD Frame The JXD63S400A is available from Industrial Automation Co. in New and IAC Certified Refurbished condition. Contact our sales team for current availability, pricing, and lead time.
-
