Siemens FXD62B100L
SKU: FXD62B100L-FS
This product is not available for online purchase.
Use the Request a quote to get the pricing
Description
Siemens FXD62B100L: a 100 A, 2-pole, 600 VAC Sentron Series molded case circuit breaker. It provides 35kA@480V interrupting rating with thermal magnetic protection.
Factory specification: 2P, 1PH, 100A, 600V, 35kA@480V, standard interrupting capacity, 40ºC, Feed-Thru, UL listed for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers.
FXD62B100L Technical Specifications
| Manufacturer | Siemens |
| Series | Sentron Series |
| Type | Molded Case Circuit Breaker |
| Connection | Feed-Thru |
| Voltage | 600 V |
| Amperage | 100 A |
| Poles | 2 |
| Phase | 1 |
| AIC Rating | 35kA@480V |
| Protection | Thermal Magnetic |
| Functions | LI - Long-Time and Instantaneous |
| Frame Type | FD Frame |
Industrial Automation Co. offers the FXD62B100L in New and IAC Certified Refurbished condition. Reach out to our sales team for availability, pricing, and lead time.
-
Buying Options
-
Description
Siemens FXD62B100L: a 100 A, 2-pole, 600 VAC Sentron Series molded case circuit breaker. It provides 35kA@480V interrupting rating with thermal magnetic protection.
Factory specification: 2P, 1PH, 100A, 600V, 35kA@480V, standard interrupting capacity, 40ºC, Feed-Thru, UL listed for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers.
FXD62B100L Technical Specifications
Manufacturer Siemens Series Sentron Series Type Molded Case Circuit Breaker Connection Feed-Thru Voltage 600 V Amperage 100 A Poles 2 Phase 1 AIC Rating 35kA@480V Protection Thermal Magnetic Functions LI - Long-Time and Instantaneous Frame Type FD Frame Industrial Automation Co. offers the FXD62B100L in New and IAC Certified Refurbished condition. Reach out to our sales team for availability, pricing, and lead time.
-
