Siemens 6SN1123-1AA00-0LA3
SKU: 6SN1123-1AA00-0LA3-R
We have 36 in stock
Estimated delivery: August 26th - August 28th
Order for next-day shipment.
- Regular price
-
$790.00
- Sale price
- $790.00
IAC Certified Refurbished
$790
36 in stock
Ships today
Description
The Siemens 6SN1123-1AA00-0LA3 is a single-axis SIMODRIVE 611 power module rated 108 A peak with internal cooling, delivering 42 A rated feed current or 45 A main-spindle current. As part of the modular SIMODRIVE 611 drive system, it pairs with SINUMERIK 810D/840D CNC controls and Siemens 1FT/1FK servo and 1PH spindle motors, and is a common service part on DMG MORI machines (cross-reference 2386551), including the DMU series.
This is the latest hardware revision of the 108 A single-axis module and is a direct, drop-in replacement for all earlier versions:
6SN1123-1AA00-0LA0
6SN1123-1AA00-0LA1
6SN1123-1AA00-0LA2
If your machine currently runs any of the part numbers above, the -0LA3 installs in its place with no modification.
Siemens has discontinued the SIMODRIVE 611 platform, making tested replacement modules the fastest way to keep legacy 810D/840D machines in production without a full drive-system retrofit.
Specifications
Series: SIMODRIVE 611
Configuration: 1-axis power module (LT module)
Peak current: 108 A
Rated current: 42 A (feed) / 45 A (main spindle)
Cooling: internal fan
Supersedes: 6SN1123-1AA00-0LA0, -0LA1, -0LA2
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $119/yr+3 yrs → 5 total $105/yr+5 yrs → 7 total $79/yrBEST VALUE+8 yrs → 10 total $59/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
DescriptionThe Siemens 6SN1123-1AA00-0LA3 is a single-axis SIMODRIVE 611 power module rated 108 A peak with internal cooling, delivering 42 A rated feed current or 45 A main-spindle current. As part of the modular SIMODRIVE 611 drive system, it pairs with SINUMERIK 810D/840D CNC controls and Siemens 1FT/1FK servo and 1PH spindle motors, and is a common service part on DMG MORI machines (cross-reference 2386551), including the DMU series.This is the latest hardware revision of the 108 A single-axis module and is a direct, drop-in replacement for all earlier versions:6SN1123-1AA00-0LA06SN1123-1AA00-0LA16SN1123-1AA00-0LA2If your machine currently runs any of the part numbers above, the -0LA3 installs in its place with no modification.Siemens has discontinued the SIMODRIVE 611 platform, making tested replacement modules the fastest way to keep legacy 810D/840D machines in production without a full drive-system retrofit.SpecificationsSeries: SIMODRIVE 611Configuration: 1-axis power module (LT module)Peak current: 108 ARated current: 42 A (feed) / 45 A (main spindle)Cooling: internal fanSupersedes: 6SN1123-1AA00-0LA0, -0LA1, -0LA2
-
Part Number Breakdown
Part number reference — 6SN1123-1AA00-0LA3
SIMODRIVE 611 POWER MODULE, 1 AXIS, INTERNAL COOLING, MOTOR RATED CURRENTS: Vorschub = 42 A Hauptspindel = 45 A
Official Siemens catalog description.
Product family SIMODRIVE 611 Power Module Series SIMODRIVE 611 Type power module Fault codes (96)
Troubleshooting reference for the SIMODRIVE 611 digital Drive System:
- Fault 300007 — Axis %1 drive %2 not present or inactive
- Fault 300008 — Axis %1 drive %2 measuring circuit %3 is not available
- Fault 300009 — Axis %1 drive %2 measuring circuit %3 wrong measuring circuit type (type %4 used)
- Fault 300010 — Axis %1 drive %2 active without NC axis assignment
- Fault 300011 — Axis %1 drive %2 hardware version of spindle not supported
- Fault 300012 — Axis %1 drive %2 hardware version of control module not supported
- Fault 300020 — Drive %1 removed for diagnostics
- Fault 300100 — Drive power failure
- Fault 300101 — Bus communications failure
- Fault 300200 — Drive bus hardware fault
- Fault 300201 — Axis %1 drive %2 timeout during access, error location %3
- Fault 300202 — Axis %1 drive %2 CRC error, error location %3
See all 96 fault codes for this series →
