Description
The Siemens 6FC5210-0DF31-2AB0 is a SINUMERIK PCU 50.3B-C panel control unit, an industrial PC that runs the HMI software of SINUMERIK 840D/840D sl CNC systems. It uses a 1.5 GHz Celeron M (CM370) processor with 512 MB RAM, is powered from 24 V DC, and ships with Windows XP Professional for Embedded Systems. The PCU 50 series supports hard-disk based HMI installations and additional Windows applications on the operator station.
Technical Specifications
| Product family | SINUMERIK 840D / 840D sl operator hardware |
| Type | Panel control unit PCU 50.3B-C |
| Processor | CM370, 1.5 GHz |
| Main memory | 512 MB RAM |
| Operating system | Windows XP Professional for Embedded Systems |
| Supply voltage | 24 V DC |
| Part number | 6FC5210-0DF31-2AB0 |
-
Buying Options
-
Description
The Siemens 6FC5210-0DF31-2AB0 is a SINUMERIK PCU 50.3B-C panel control unit, an industrial PC that runs the HMI software of SINUMERIK 840D/840D sl CNC systems. It uses a 1.5 GHz Celeron M (CM370) processor with 512 MB RAM, is powered from 24 V DC, and ships with Windows XP Professional for Embedded Systems. The PCU 50 series supports hard-disk based HMI installations and additional Windows applications on the operator station.
Technical Specifications
Product family SINUMERIK 840D / 840D sl operator hardware Type Panel control unit PCU 50.3B-C Processor CM370, 1.5 GHz Main memory 512 MB RAM Operating system Windows XP Professional for Embedded Systems Supply voltage 24 V DC Part number 6FC5210-0DF31-2AB0 -
Part Number Breakdown
Part number reference — 6FC5210-0DF31-2AB0
SINUMERIK PCU 50.3B-C electronic control unit CM370; 1.5 GHz; 1x 512 MB RAM 24 V DC; Windows XP Professional for embedded systems (Windows XP Professional for Embedded Systems)
Official Siemens catalog description.
Product family SINUMERIK 810D/840D MMC 100/101 Operator Interface Unit Series SINUMERIK 840D Type hmi panel Questions or need a quote? Call 877-727-8757 or email sales@iac.us.com.
-
