Siemens 6ES7235-0KD22-0XA0
SKU: 6ES7235-0KD22-0XA0-FS
1 in stock
Estimated delivery: November 10th - November 12th
Order for next-day shipment.
- Regular price
- $286.00
- Sale price
- $286.00
New
$286
In Stock
Description
The Siemens 6ES7235-0KD22-0XA0 is a SIMATIC S7-200 EM 235 analog combination module for use with S7-22X series CPUs. It provides 4 analog inputs and 1 analog output with 12-bit conversion, allowing a compact S7-200 controller to read process signals such as pressure, level, or temperature transmitters and drive a single analog actuator or drive speed reference.
The EM 235 connects to the CPU expansion bus and is configured with DIP switches for input range selection. Shielded wiring is recommended for analog signal runs.
Technical Specifications
| Series | SIMATIC S7-200, EM 235 |
| Module type | Analog input/output expansion module |
| Analog inputs | 4, +/-10 V DC (configurable ranges) |
| Analog outputs | 1, +/-10 V DC |
| Resolution | 12-bit converter |
| Compatible CPUs | S7-22X (CPU 222, 224, 224XP, 226) |
| Supply voltage | 24 V DC |
| Mounting | S7-200 expansion bus, DIN rail or panel |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $43/yr+3 yrs → 5 total $38/yr+5 yrs → 7 total $29/yrBEST VALUE+8 yrs → 10 total $21/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Siemens 6ES7235-0KD22-0XA0 is a SIMATIC S7-200 EM 235 analog combination module for use with S7-22X series CPUs. It provides 4 analog inputs and 1 analog output with 12-bit conversion, allowing a compact S7-200 controller to read process signals such as pressure, level, or temperature transmitters and drive a single analog actuator or drive speed reference.
The EM 235 connects to the CPU expansion bus and is configured with DIP switches for input range selection. Shielded wiring is recommended for analog signal runs.
Technical Specifications
Series SIMATIC S7-200, EM 235 Module type Analog input/output expansion module Analog inputs 4, +/-10 V DC (configurable ranges) Analog outputs 1, +/-10 V DC Resolution 12-bit converter Compatible CPUs S7-22X (CPU 222, 224, 224XP, 226) Supply voltage 24 V DC Mounting S7-200 expansion bus, DIN rail or panel -
Part Number Breakdown
Part number reference — 6ES7235-0KD22-0XA0
SIMATIC S7-200, analog I/O EM 235, only for S7-22X CPU, 4 AI, +/-10 V DC; 1 AO, +/-10 V DC 12 bit converter
Official Siemens catalog description.
