ProSoft MVI56-MBP
SKU: MVI56-MBP-R
1 in stock
Estimated delivery: November 10th - November 12th
Order for next-day shipment.
- Regular price
- $790.00
- Sale price
- $790.00
IAC Certified Refurbished
$790
In Stock
New
Call for Availability
Request a quote
Description
The ProSoft Technology MVI56-MBP is a Modbus Plus communication module for 1756-format in-chassis platforms. It operates as a bidirectional master/slave gateway to Modicon-style and other Modbus Plus devices, with a 4000-word data memory for asynchronous transfers between the network and the host controller.
A rechargeable Lithium-Vanadium backup battery preserves module data for up to 21 days without power. The module occupies a single chassis slot.
Technical Specifications
| Manufacturer | ProSoft Technology |
| Part Number | MVI56-MBP |
| Product Type | Modbus Plus communication module |
| Operation | Bidirectional master/slave gateway |
| Data Memory | 4000 words |
| Backup Battery | Rechargeable Lithium-Vanadium, up to 21 days retention |
| Slot Requirement | Single slot |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $119/yr+3 yrs → 5 total $105/yr+5 yrs → 7 total $79/yrBEST VALUE+8 yrs → 10 total $59/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The ProSoft Technology MVI56-MBP is a Modbus Plus communication module for 1756-format in-chassis platforms. It operates as a bidirectional master/slave gateway to Modicon-style and other Modbus Plus devices, with a 4000-word data memory for asynchronous transfers between the network and the host controller.
A rechargeable Lithium-Vanadium backup battery preserves module data for up to 21 days without power. The module occupies a single chassis slot.
Technical Specifications
Manufacturer ProSoft Technology Part Number MVI56-MBP Product Type Modbus Plus communication module Operation Bidirectional master/slave gateway Data Memory 4000 words Backup Battery Rechargeable Lithium-Vanadium, up to 21 days retention Slot Requirement Single slot -
Specifications
Manufacturer and Product Information
Part Number/Catalog No. MVI56-MBP Product Type Modbus Plus Dual Port Network Interface Module Slot(s) 1 Rack Type Local or Remote Data Transfer Specifications
Data Transfer Type Ladder Logic Baud 57,600 Max. Word Reads and Writes 100 Master Command Count 0 to 200 Commands Module Data Transfer 0 to 4000 Words Backplane Current Load 800 mA at 5 Volts DC -
