allen-bradley-mvi56-dfcm

ProSoft MVI56-DFCM

SKU: MVI56-DFCM-FS

Estimated delivery: June 26th - June 28th

Order for next-day shipment.

This product is not available for online purchase.

Use the Request a quote to get the pricing

Surplus Original Box
Available
Request a quote

Description

The ProSoft MVI56-DFCM is a DF1 Master/Slave communication module for ControlLogix, bridging SCADA, HMI, and legacy DF1 serial devices with Rockwell controllers. With dual serial ports, it provides full and half-duplex DF1 protocol flexibility.

  • Two RS-232/422/485 ports (Master/Slave)
  • Baud rate: up to 115,200 bps
  • Voltage: 5–24 VDC; current draw: 3–800 mA
  • CRC/BCC checking, retries, and status LEDs
  • Operating: 32–140 °F
More payment options

Secure payment options

  • Guaranteed response within 24 hours

    Submit an RFQ and receive a quick, reliable quote from our team to keep your operations moving.

    More about shipping

  • 24 month warranty

    Twice the industry standard—full protection against defects for 2 full years.

    More about warranty

  • Multiple conditions available

    Multiple sourcing paths to help you control costs without compromising performance.

    More about warranty

  • Best catalog

    Large U.S. inventory and fast sourcing for Mitsubishi, Siemens, Schneider & more.

    Read More
  • Buying Options

    All products are covered by Industrial Automation Co.'s 2-Year Warranty.

    Condition SKU Price Warranty Availability Quantity Purchase
    Surplus Original Box MVI56-DFCM-FS 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
  • Description

    The ProSoft MVI56-DFCM is a DF1 Master/Slave communication module for ControlLogix, bridging SCADA, HMI, and legacy DF1 serial devices with Rockwell controllers. With dual serial ports, it provides full and half-duplex DF1 protocol flexibility.

    • Two RS-232/422/485 ports (Master/Slave)
    • Baud rate: up to 115,200 bps
    • Voltage: 5–24 VDC; current draw: 3–800 mA
    • CRC/BCC checking, retries, and status LEDs
    • Operating: 32–140 °F
  • Specifications

    Manufacturer and Product Information
    Part Number/Catalog No.MVI56-DFCM
    Product TypeDF1 Master/Slave Network Interface Module
    Slot(s)1
    Rack TypeLocal or Remote

    Technical Specifications
    Data Transfer TypeLadder Logic
    Baud Rate110 to 115200 Baud
    Read Write Command Length125 words maximum
    Memory UsageUser-configurable
    Shock30G Operational
    Backplane Current Load800 mA at 5 Volts DC
