Omron MS46SR-30-700-Q1-R-NO-FP
SKU: MS46SR-30-700-Q1-R-NO-FP-R
We have 1 in stock
Estimated delivery: August 31st - September 2nd
Order for next-day shipment.
- Regular price
-
$549.00
- Sale price
- $549.00
IAC Certified Refurbished
$549
1 in stock
Ships today
Description
The Omron MS46SR-30-700-Q1-R-NO-FP is a receiver module from the MS4600SR series of safety light curtains. Paired with the matching transmitter, it monitors a 700 mm (approx. 27.5 inch) protective field with 30 mm resolution optimized for hand detection, switching its dual safety outputs when the field is interrupted.
The unit provides dual PNP sourcing safety outputs and front programming (FP) capability, with an M12 8-pin quick-disconnect for fast replacement in machine guarding installations.
Technical Specifications
| Series | MS4600SR safety light curtain |
| Unit type | Receiver module |
| Protective height | 700 mm (approx. 27.5 in) |
| Object resolution | 30 mm (hand detection) |
| Operating range | 0.3 to 9.0 m |
| Safety outputs | Dual PNP sourcing, 500 mA max, normally open |
| Supply voltage | 24 VDC (+/- 20%) |
| Current consumption | 1.4 A |
| Connection | Q1 quick-disconnect, M12 8-pin |
| Enclosure rating | IP65 / NEMA 4, 12 |
| Weight | Approx. 1.47 kg (3.25 lb) |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $82/yr+3 yrs → 5 total $73/yr+5 yrs → 7 total $55/yrBEST VALUE+8 yrs → 10 total $41/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Omron MS46SR-30-700-Q1-R-NO-FP is a receiver module from the MS4600SR series of safety light curtains. Paired with the matching transmitter, it monitors a 700 mm (approx. 27.5 inch) protective field with 30 mm resolution optimized for hand detection, switching its dual safety outputs when the field is interrupted.
The unit provides dual PNP sourcing safety outputs and front programming (FP) capability, with an M12 8-pin quick-disconnect for fast replacement in machine guarding installations.
Technical Specifications
Series MS4600SR safety light curtain Unit type Receiver module Protective height 700 mm (approx. 27.5 in) Object resolution 30 mm (hand detection) Operating range 0.3 to 9.0 m Safety outputs Dual PNP sourcing, 500 mA max, normally open Supply voltage 24 VDC (+/- 20%) Current consumption 1.4 A Connection Q1 quick-disconnect, M12 8-pin Enclosure rating IP65 / NEMA 4, 12 Weight Approx. 1.47 kg (3.25 lb) -
