Maple Systems SM022011
SKU: SM022011
In stock
Authorized-brand item: ships per the manufacturer's lead time.
- Regular price
- $0.00
- Sale price
- $0.00
New
$0
In stock
Description
The Maple Systems SM022011 is a 1000Base-SX SFP transceiver module for gigabit Ethernet over multimode fiber. It operates at 850 nm with a reach of up to 550 m over duplex LC multimode fiber, and plugs into the SFP port of the Maple Systems MS1-L05G01F managed Ethernet switch for short-haul fiber links inside a plant or between nearby cabinets.
A fiber optic patch cable (such as the SC020002/SC020003/SC020006 OM3 duplex cables) is required and sold separately.
Technical Specifications
| Part Number | SM022011 |
| Type | SFP transceiver module |
| Standard | 1000Base-SX |
| Data Rate | 1.25 Gbps |
| Wavelength | 850 nm |
| Reach | Up to 550 m |
| Connector | Dual LC |
| Fiber Type | Multimode (MMF) |
| Typical Use | SFP port of MS1-L05G01F switch |
-
Buying Options
-
Description
The Maple Systems SM022011 is a 1000Base-SX SFP transceiver module for gigabit Ethernet over multimode fiber. It operates at 850 nm with a reach of up to 550 m over duplex LC multimode fiber, and plugs into the SFP port of the Maple Systems MS1-L05G01F managed Ethernet switch for short-haul fiber links inside a plant or between nearby cabinets.
A fiber optic patch cable (such as the SC020002/SC020003/SC020006 OM3 duplex cables) is required and sold separately.
Technical Specifications
Part Number SM022011 Type SFP transceiver module Standard 1000Base-SX Data Rate 1.25 Gbps Wavelength 850 nm Reach Up to 550 m Connector Dual LC Fiber Type Multimode (MMF) Typical Use SFP port of MS1-L05G01F switch -
