Dobot CR10ACollaborativeRobot
SKU:
12 in stock
Authorized-brand item: ships per the manufacturer's lead time.
- Regular price
- $31,960.00
- Sale price
- $31,960.00
New
$31,960
In Stock
Description
The Dobot CR10A is a six-axis collaborative robot in the CR-A series, rated for a 10 kg payload with a 1300 mm working radius. It is designed for high-speed, extended-reach handling work and can typically be deployed within an hour using Dobot's graphical programming environment. Tool speeds reach up to 4 m/s with +/-0.03 mm repeatability.
Typical applications include palletizing, machine tending, loading and unloading, and transport tasks in logistics, automotive, and metal processing.
Technical Specifications
| Manufacturer | Dobot |
| Series | CR-A |
| Type | Collaborative robot (cobot) |
| Axes | 6 |
| Payload | 10 kg |
| Reach | 1300 mm |
| Repeatability | +/-0.03 mm |
| Max Tool Speed | 4 m/s |
| Communications | TCP/IP, Modbus, EtherNet/IP, PROFINET (per series) |
-
Buying Options
-
Description
The Dobot CR10A is a six-axis collaborative robot in the CR-A series, rated for a 10 kg payload with a 1300 mm working radius. It is designed for high-speed, extended-reach handling work and can typically be deployed within an hour using Dobot's graphical programming environment. Tool speeds reach up to 4 m/s with +/-0.03 mm repeatability.
Typical applications include palletizing, machine tending, loading and unloading, and transport tasks in logistics, automotive, and metal processing.
Technical Specifications
Manufacturer Dobot Series CR-A Type Collaborative robot (cobot) Axes 6 Payload 10 kg Reach 1300 mm Repeatability +/-0.03 mm Max Tool Speed 4 m/s Communications TCP/IP, Modbus, EtherNet/IP, PROFINET (per series) -
