Delta ECMA-F1221BS3
SKU: ECMA-F1221BS3
This product is not available for online purchase.
Use Request a quote to get pricing.
Description
Delta ECMA-F1221BS3 AC Servo Motor
The Delta ECMA-F1221BS3 is a 22 kW AC servo motor with an integrated brake, tailored for high-power industrial applications that require precise stopping and holding capabilities. Operating at 1500 RPM, it provides a rated torque of 140 Nm, ensuring accurate and reliable motion control.
- Rated Output Power: 22 kW
- Rated Speed: 1500 RPM
- Rated Torque: 140 Nm
- Voltage Rating: 380 VAC
- Frame Size: 220 mm
- Encoder Type: 20-bit Incremental
- Shaft Type: Keyway with Oil Seal
- Brake: Included
- Weight: Approximately 100 kg
Ideal for large-scale automation systems, heavy-duty machinery, and applications where precise positioning and braking are critical.
-
Buying Options
-
Description
Delta ECMA-F1221BS3 AC Servo Motor
The Delta ECMA-F1221BS3 is a 22 kW AC servo motor with an integrated brake, tailored for high-power industrial applications that require precise stopping and holding capabilities. Operating at 1500 RPM, it provides a rated torque of 140 Nm, ensuring accurate and reliable motion control.
- Rated Output Power: 22 kW
- Rated Speed: 1500 RPM
- Rated Torque: 140 Nm
- Voltage Rating: 380 VAC
- Frame Size: 220 mm
- Encoder Type: 20-bit Incremental
- Shaft Type: Keyway with Oil Seal
- Brake: Included
- Weight: Approximately 100 kg
Ideal for large-scale automation systems, heavy-duty machinery, and applications where precise positioning and braking are critical.
-
