Cutler Hammer CHND4800T32W
SKU: CHND4800T32W-FS
This product is not available for online purchase.
Use the Request a quote to get the pricing
Description
The Cutler Hammer CHND4800T32W is a Series C molded case circuit breaker rated 800 A, 4-pole, 600 VAC. It provides 65kA@480V interrupting rating with solid state protection.
Factory specification: Eaton,Westinghouse, Series C, 4P, 3PH, 800A, 600V, 65kA@480V, high interrupting capacity, Bolt-On, 100% rated, complete with non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, lugs and rating plug not included, Digitrip RMS 310 Solid State electronic, molded case circuit breakers.
CHND4800T32W Technical Specifications
| Manufacturer | Cutler Hammer |
| Series | Series C |
| Type | Molded Case Circuit Breaker |
| Connection | Bolt-On |
| Voltage | 600 V |
| Amperage | 800 A |
| Poles | 4 |
| Phase | 3 |
| AIC Rating | 65kA@480V |
| Protection | Solid State |
| Functions | LSI - Long-Time, Short-Time and Instantaneous |
| Frame Type | N Frame |
The CHND4800T32W is available from Industrial Automation Co. in New and IAC Certified Refurbished condition. Contact our sales team for current availability, pricing, and lead time.
-
Buying Options
-
Description
The Cutler Hammer CHND4800T32W is a Series C molded case circuit breaker rated 800 A, 4-pole, 600 VAC. It provides 65kA@480V interrupting rating with solid state protection.
Factory specification: Eaton,Westinghouse, Series C, 4P, 3PH, 800A, 600V, 65kA@480V, high interrupting capacity, Bolt-On, 100% rated, complete with non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, lugs and rating plug not included, Digitrip RMS 310 Solid State electronic, molded case circuit breakers.
CHND4800T32W Technical Specifications
Manufacturer Cutler Hammer Series Series C Type Molded Case Circuit Breaker Connection Bolt-On Voltage 600 V Amperage 800 A Poles 4 Phase 3 AIC Rating 65kA@480V Protection Solid State Functions LSI - Long-Time, Short-Time and Instantaneous Frame Type N Frame The CHND4800T32W is available from Industrial Automation Co. in New and IAC Certified Refurbished condition. Contact our sales team for current availability, pricing, and lead time.
-
