Beckhoff EL3356
SKU: EL3356-FS
We have 2 in stock
Estimated delivery: September 25th - September 27th
Order for next-day shipment.
- Regular price
-
$312.00
- Sale price
- $312.00
New
$312
2 in stock
Ships today
Description
The Beckhoff EL3356 is a 1-channel precision analog input terminal for resistor bridges (strain gauges and load cells) in the EtherCAT Terminal system. It directly evaluates a full-bridge measuring bridge with 16-bit resolution and includes self-calibration and automatic zero balancing functions for weighing and force measurement applications.
The terminal measures the bridge supply and differential bridge signal, computing the load value on board, which makes it a compact alternative to an external weighing amplifier.
Technical Specifications
| Manufacturer | Beckhoff |
| Series | EtherCAT Terminal |
| Function | 1-channel analog input, measuring bridge |
| Bridge type | Full bridge, differential signal |
| Resolution | 16 bit |
| E-bus current | 210 mA |
| Operating temperature | 0 to +55 deg C |
| Protection rating | IP20 |
| Mounting | 35 mm DIN rail |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $47/yr+3 yrs → 5 total $42/yr+5 yrs → 7 total $31/yrBEST VALUE+8 yrs → 10 total $23/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Beckhoff EL3356 is a 1-channel precision analog input terminal for resistor bridges (strain gauges and load cells) in the EtherCAT Terminal system. It directly evaluates a full-bridge measuring bridge with 16-bit resolution and includes self-calibration and automatic zero balancing functions for weighing and force measurement applications.
The terminal measures the bridge supply and differential bridge signal, computing the load value on board, which makes it a compact alternative to an external weighing amplifier.
Technical Specifications
Manufacturer Beckhoff Series EtherCAT Terminal Function 1-channel analog input, measuring bridge Bridge type Full bridge, differential signal Resolution 16 bit E-bus current 210 mA Operating temperature 0 to +55 deg C Protection rating IP20 Mounting 35 mm DIN rail -
