FANUC A06B-6134-H303#A
SKU: A06B-6134-H303#A-FS
1 in stock
Estimated delivery: November 10th - November 12th
Order for next-day shipment.
- Regular price
- $5,554.00
- Sale price
- $5,554.00
New
$5,554
In Stock
IAC Certified Refurbished
Call for Availability
Request a quote
Description
The FANUC A06B-6134-H303#A is a three-axis servo amplifier module from the Beta i series. It controls the positioning and movement of up to three FANUC Beta i servo motors from a single unit, making it a common drive for compact CNC machine tools and automation systems.
The module distributes power across its L, M, and N axes with a rated output current of 13 A per axis and a 63 A class rating overall, supporting accurate multi-axis motor control from one amplifier package.
Technical Specifications
| Manufacturer | FANUC |
| Series | Beta i (A06B-6134) |
| Type | Servo amplifier module |
| Axes | 3 (L, M, N) |
| Rated Output Current per Axis | 13 A |
| Amplifier Class | 63 A |
| Typical Application | Multi-axis servo control on FANUC CNC systems |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $833/yr+3 yrs → 5 total $741/yr+5 yrs → 7 total $555/yrBEST VALUE+8 yrs → 10 total $417/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The FANUC A06B-6134-H303#A is a three-axis servo amplifier module from the Beta i series. It controls the positioning and movement of up to three FANUC Beta i servo motors from a single unit, making it a common drive for compact CNC machine tools and automation systems.
The module distributes power across its L, M, and N axes with a rated output current of 13 A per axis and a 63 A class rating overall, supporting accurate multi-axis motor control from one amplifier package.
Technical Specifications
Manufacturer FANUC Series Beta i (A06B-6134) Type Servo amplifier module Axes 3 (L, M, N) Rated Output Current per Axis 13 A Amplifier Class 63 A Typical Application Multi-axis servo control on FANUC CNC systems -
Part Number Breakdown
Part number breakdown — A06B-6134-H303#A
βi SVPM Combined Servo & Spindle Amplifier (SVPM)
Model H303SVPM3-15i Option suffix AType A sensor function Specifications
axes 3 spindleKw 15 inputVoltage 200-240VAC +10%,-15%, 50/60Hz inputCurrentArms 64 powerSupplyRatingKva 22 spindleRatedCurrentArms 64 axis1RatedCurrentArms 13 axis2RatedCurrentArms 13 axis3RatedCurrentArms 13 axis1RatingA 40 axis2RatingA 40 axis3RatingA 40 weightKg 14.8 powerPcb A20B-2101-0025 controlPcb A20B-2101-0013 Alarm codes (141)
Full troubleshooting reference for this servo spindle amplifier:
- Alarm SV0027 — Invalid digital servo parameter setting
- Alarm SV0361 — Pulsecoder phase error (built-in)
- Alarm SV0364 — Soft phase alarm (built-in)
- Alarm SV0365 — LED error (built-in)
- Alarm SV0366 — Pulse error (built-in)
- Alarm SV0367 — Count error (built-in)
- Alarm SV0368 — Serial data error (built-in)
- Alarm SV0369 — Data transfer error (built-in)
- Alarm SV0380 — LED error (separate)
- Alarm SV0381 — Pulsecoder phase error (separate)
- Alarm SV0382 — Count error (separate)
- Alarm SV0383 — Pulse error (separate)
See all 141 alarm codes for this series →
Documentation
Decoded from FANUC documentation (B-65322EN/02). Questions? Call 877-727-8757 or email sales@iac.us.com.
-
