SKU: A06B-6079-H206#EM-R
Estimated delivery: November 24th - November 26th
Order for next-day shipment.
The FANUC A06B-6079-H206#EM is an Alpha series Servo Amplifier Module, model SVM2-40/40, in the #EM variant. This two-axis module drives two 40-class FANUC Alpha servo motors from the common DC link supplied by the Alpha Power Supply Module, providing precise digital control of both axes.
Each axis delivers a 12.5 A class rated output at up to 230 VAC, suiting mid-size feed axes on CNC machining centers and lathes.
| Manufacturer | FANUC |
| Part Number | A06B-6079-H206#EM |
| Product Type | Servo amplifier module |
| Series | FANUC Alpha drive system |
| Model | SVM2-40/40 |
| Axes | 2 |
| Rated Output Current | 12.5 A class per axis |
| Maximum Output Voltage | 230 VAC |
| DC Link Input | 283-325 VDC (from PSM) |
| Application | CNC feed axes |
Extended plans are available at checkout on items $200 and up.
The FANUC A06B-6079-H206#EM is an Alpha series Servo Amplifier Module, model SVM2-40/40, in the #EM variant. This two-axis module drives two 40-class FANUC Alpha servo motors from the common DC link supplied by the Alpha Power Supply Module, providing precise digital control of both axes.
Each axis delivers a 12.5 A class rated output at up to 230 VAC, suiting mid-size feed axes on CNC machining centers and lathes.
| Manufacturer | FANUC |
| Part Number | A06B-6079-H206#EM |
| Product Type | Servo amplifier module |
| Series | FANUC Alpha drive system |
| Model | SVM2-40/40 |
| Axes | 2 |
| Rated Output Current | 12.5 A class per axis |
| Maximum Output Voltage | 230 VAC |
| DC Link Input | 283-325 VDC (from PSM) |
| Application | CNC feed axes |
α Series Servo Amplifier Module SVM (Type A/B interface, 200-V input)
Amplifier modelH206 | SVM2-40/40 |
| axes | 2 |
| axis1LimitA | 40 |
| axis2LimitA | 40 |
| axis1RatedCurrentArms | 12.5 |
| axis2RatedCurrentArms | 12.5 |
| weightKg | 5.5 |
Full troubleshooting reference for this servo amplifier:
See all 17 alarm codes for this series →
Decoded from FANUC documentation (B-65162E/03). Questions? Call 877-727-8757 or email sales@iac.us.com.
