Siemens 6ES7314-6CH04-0AB0
SKU: 6ES7314-6CH04-0AB0-FS
1 in stock
Estimated delivery: October 27th - October 29th
Order for next-day shipment.
- Regular price
- $1,193.00
- Sale price
- $1,193.00
New
$1,193
In Stock
Description
The Siemens 6ES7314-6CH04-0AB0 is a SIMATIC S7-300 CPU 314C-2 DP compact CPU combining a mid-range processor with extensive onboard I/O and an integrated PROFIBUS DP interface. Onboard resources include 24 digital inputs, 16 digital outputs, 4 analog inputs, 2 analog outputs, one Pt100 input, and 4 high-speed counters (60 kHz), covering many machine control applications without extra signal modules.
Front connectors (2x 40-pin) and a Micro Memory Card are required and sold separately. This version supersedes 6ES7314-6CF00-0AB0 and 6ES7314-6CF02-0AB0. Dimensions approx. 120 x 125 x 130 mm, current consumption approx. 500 mA at 24 V DC.
Technical Specifications
| Series | SIMATIC S7-300, CPU 314C-2 DP (compact) |
| Work memory | 192 KB |
| Onboard digital I/O | 24 DI / 16 DO, 24 V DC |
| Onboard analog I/O | 4 AI, 2 AO, 1 Pt100 |
| High-speed counters | 4 channels, 60 kHz |
| Interfaces | MPI; PROFIBUS DP master/slave |
| Supply voltage | 24 V DC (integrated) |
| Load memory | Micro Memory Card (required, not included) |
| Front connectors | 2x 40-pin (required, not included) |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $179/yr+3 yrs → 5 total $159/yr+5 yrs → 7 total $119/yrBEST VALUE+8 yrs → 10 total $89/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Siemens 6ES7314-6CH04-0AB0 is a SIMATIC S7-300 CPU 314C-2 DP compact CPU combining a mid-range processor with extensive onboard I/O and an integrated PROFIBUS DP interface. Onboard resources include 24 digital inputs, 16 digital outputs, 4 analog inputs, 2 analog outputs, one Pt100 input, and 4 high-speed counters (60 kHz), covering many machine control applications without extra signal modules.
Front connectors (2x 40-pin) and a Micro Memory Card are required and sold separately. This version supersedes 6ES7314-6CF00-0AB0 and 6ES7314-6CF02-0AB0. Dimensions approx. 120 x 125 x 130 mm, current consumption approx. 500 mA at 24 V DC.
Technical Specifications
Series SIMATIC S7-300, CPU 314C-2 DP (compact) Work memory 192 KB Onboard digital I/O 24 DI / 16 DO, 24 V DC Onboard analog I/O 4 AI, 2 AO, 1 Pt100 High-speed counters 4 channels, 60 kHz Interfaces MPI; PROFIBUS DP master/slave Supply voltage 24 V DC (integrated) Load memory Micro Memory Card (required, not included) Front connectors 2x 40-pin (required, not included) -
Part Number Breakdown
Part number reference — 6ES7314-6CH04-0AB0
SIMATIC S7-300, CPU 314C-2 DP Compact CPU with MPI, 24 DI/16 DO, 4 AI, 2 AO, 1 Pt100, 4 high-speed counters (60 kHz), integrated DP interface, Integr. power supply 24 V DC, work memory 192 KB, Front connector (2x 40-pole) and Micro Memory Card required
Official Siemens catalog description.
Product family SIMATIC S7-300 CPU 314 Series SIMATIC S7-300 Type plc cpu Questions or need a quote? Call 877-727-8757 or email sales@iac.us.com.
-
