The Mitsubishi HC-MF73K-D52 is a high-performance AC servo motor for precise and efficient motion control in various industrial applications. This Mitsubishi HC-MF series component servo motor is renowned for its energy efficiency, high torque, and reliability. Delivering consistent performance in demanding environments, the model is optimal for duties requiring precise positioning and smooth operation.

Technical Specifications:

The Mitsubishi HC-MF73K-D52 AC servo motor produces 0.75 kW at 3000 rpm. Its top speed is 4500 RPM. The motor produces 7.16 Nm of maximum torque and 2.39 Nm of rated torque. It can run at a 3.2 A rated current and a 9.6 A peak current, ensuring constant performance with various loads.

The HC-MF73K-D52's 0.143 kg ·m ² rotor inertia enables accurate control and quick response. This device operates at 50/60 Hz and 200 V. Class F insulation provides reliable heat protection.

The non-condensing Mitsubishi HC-MF73K-D52 tolerates 20%à ¢ ‚ ¬ € œ80% humidity. It can endure shocks of 19.6 m/s ² and vibrations of 4.9 m/s ², ensuring durability in intensive applications. The motor uses natural ventilation and has a plug-in connector for easy installation. It has a straight shaft, keyway, and ball bearings for smooth operation.

The 8-pole servo motor can support 98 N axially and 196 N radially. It produces 2.39 Nm sustained torque and 0.143 kg ·m ² moment of inertia. The incremental encoder ensures precise positioning with 131072 pulses per revolution.

HC-MF73K-D52 is 90% effective and has a 200 V rated voltage. It can tolerate 300% of the rated current for three seconds to handle short-term load spikes. CE, UL, and RoHS certifications ensure the motor's safety and environmental compliance.

The axial and radial load limits are 98 N and 196 N, respectively. This motor is IP65-rated and can endure temperatures of 155 Degrees Celsius. Its twenty thousand-hour lifespan makes it a reliable choice for years. In this circuit, the power factor is 0.85, and the torque constant is 0.3 Nm/A. Installing a dynamic brake improves control.

Mounting :

The Mitsubishi HC-MF73K-D52 is equipped with flange mounting, guaranteeing a secure and stable installation. This mounting type is adaptable and effortless to integrate, making it appropriate for various industrial configurations. The motor's plug-in connector type enables rapid and uncomplicated electrical connections, minimizing installation time and effort.

Safety Specifications and Precautions:

For optimal performance, the motor must be stored between -20 °C and 80 °C and operated within the specified ambient temperature range of 0 °C to 40 °C. To prevent moisture-related issues, humidity should be maintained between 20% and 80% (non-condensing). To prevent injury, the maximum vibration and shock speeds should be 4.9 m/s ² and 19.6 m/s ², respectively.

The HC-MF73K-D52 is compliant with CE, UL, and RoHS standards, guaranteeing compliance with environmental and safety regulations. Adhering to appropriate handling and installation protocols is imperative to assure longevity and safety. Routine maintenance and inspections are also advisable to ensure that the motor operates proficiently throughout its service life.

Frequently Asked Questions:

What is the HC-MF73K-D52's rated torque and peak torque?

A peak torque of 7.16 Nm and a rated torque of 2.39 Nm are provided by the Mitsubishi HC-MF73K-D52. That way, you know the motor can quickly adapt to different loads.

In what ways does the HC-MF73K-D52 excel in insulation and protection?

The Mitsubishi HC-MF73K-D52 is protected to IP65 and has a Class F insulation class. This results in dependable thermal protection and a product that can withstand tough situations.

What is the HC-MF73K-D52's mounting type and weight?

Flange mounting is standard on the 2.7-kilogram Mitsubishi HC-MF73K-D52. This makes sure that the installation is secure and that it can be easily integrated into various systems.
