Yaskawa CIMR-JU4A0004BAA

Manufacturer Part Number CIMR-VU4A0004FAA
Manufacturer Yaskawa
Product Series V1000
Family Series Yaskawa Drives, V1000 Series
Description Drive, AC, 1HP, 480V, 3PH, 3.4A, CT, N1 2HP, 4.1A, VT 5.89in.Hx4.25in.Wx5.41in.D
Input Phase 3
HP (Constant Torque Rating) 1 hp
HP (Variable Torque Rating) 2 hp
Amps (Constant Torque Rating) 3.4 A
Amps (Variable Torque Rating) 4.1 A
Braking Type DC Injection, Dynamic Braking Transistor Included
Closed Loop No
AC Line Regenerative No
Operator Controls Built In
NEMA Rating NEMA 1
Motor Control-Max Level Open Loop Vector (Sensorless Vector)
Mounting Panel
Nominal Input Voltage 380 VAC, 415 VAC, 480 VAC
AC Voltage 380-480 VAC
Frequency 400 Hz
Dynamic Braking Trans Included
Height 5.89 "
Width 4.25 "
Depth 5.41 "
Net Weight 3.47 lbs
Gross Weight 5 lbs
