Toshiba VFS15-2110PM-W1

Toshiba VFS15-2110PM-W1

One high-performance industrial variable speed drive from Toshiba's TOSVERT VF-S15 series is the VFS15-2110PM-W1. This drive can handle three-phase induction motors and is built for precise motor control in demanding industrial applications. It is the perfect option for improving motor efficiency and operating dependability due to its solid features and cutting-edge technology.

Technical Specifications

With a capacity of 20.6 kVA, the Toshiba VFS15-2110PM-W1 inverter is ideal for use with 11 kW motors. With a rated output current of 54.0 A, it can withstand temperatures as low as 40 °C. To meet the needs of the motor, the device takes an input voltage of 240V in three phases and produces an output voltage ranging from 200V to 240V.

With an overload current rating of 150% for 60 seconds and 200% for 0.5 seconds, this model performs exceptionally well under different load conditions. The frequency tolerance is ±5%, and the permissible voltage variation is between 170V and 264V.

The VFS15-2110PM-W1 inverter has high power requirements for proper functioning, as indicated by its needed power supply capacity of 24.3 kVA. Its defence mechanism is up to IP20 standards, which means it can withstand moderate dust and water but not much more. Optimal operating temperatures are maintained with the use of forced air cooling, which increases the device's performance and longevity.

Environmental and Safety Considerations

The Toshiba VFS15-2110PM-W1 is best used indoors, away from anything that could cause damage, such as strong sunlight, combustible gases, explosive conditions, oil mist, or an abundance of dust. Its construction guarantees steady functioning in standard industrial settings by withstanding vibrations up to 55 Hz, with velocities no greater than 5.9 m/s². At heights up to 3000 meters, the inverter works efficiently; however, at elevations over 1000 meters, a reduction in current is necessary.

With an operational temperature range of -10°C to +60°C, this inverter is suitable for various climates. You may keep it anywhere from -25°C to +70°C when unused. The gadget is reliable in multiple humidity situations and can withstand relative humidity levels from 5 to 95% as long as it doesn't get wet or contain any vapor.

Electrical and Installation Details

The VFS15-2110PM-W1 is best used with Class J 100 breakers to prevent overcurrents. Despite the lack of a fuse rating, it is essential to follow standard procedures for protecting circuits. The inverter's reliable operation is guaranteed by the necessary electrical characteristics, which include a minimum input inductance of 0.02 mH.

The power circuit should utilize AWG 6*2 wire, and the earth cable should use AWG 8 wire for a safe and effective installation. As stated in these standards, the electrical connections must sustain the necessary current load without experiencing excessive heating or noticeable voltage dips. The GV3P65 and other suitable circuit breakers guarantee the protection of the branch circuits.

Frequently Asked Questions

The Toshiba VFS15-2110PM-W1 uses what kind of cooling system?

Toshiba VFS15-2110PM-W1 uses forced air cooling. This keeps the inverter at the appropriate operating temperature range in challenging industrial situations, improving performance and durability.

What is the protection rating of the Toshiba VFS15-2110PM-W1 inverter?

The IP20-rated Toshiba VFS15-2110PM-W1 is protected. Due to its low water and dust protection, this category is suitable for indoor use.

What are the Toshiba VFS15-2110PM-W1's recommended power and ground cable sizes?

For the Toshiba VFS15-2110PM-W1, AWG 6*2 is used for the power circuit, and AWG 8 is used for the earth cable. These standards guarantee safe, efficient electrical connections.

Product Specifications Table:
