Siemens 6SN1146-1AB00-0BA1
SKU: 6SN1146-1AB00-0BA1-NSO
We have 1 in stock
Estimated delivery: September 1st - September 3rd
Order for next-day shipment.
- Regular price
-
$1,850.00
- Sale price
- $1,850.00
New Open Box
$1,850
1 in stock
Ships today
IAC Certified Refurbished
$690
2 in stock
Ships today
Description
The Siemens 6SN1146-1AB00-0BA1 is a SIMODRIVE 611 unregulated infeed module (UE) rated 5 kW / 10 kW peak. It rectifies the 3-phase 400 V supply to the 600 V DC link that feeds the power modules of the drive group; braking energy is dissipated in a pulsed resistor rather than returned to the mains. The infeed module is the first module in every SIMODRIVE 611 drive group and is a standard service part on SINUMERIK-controlled CNC machine tools.
Technical Specifications
| Series | SIMODRIVE 611 |
| Type | Unregulated infeed module (UE) |
| Power rating | 5 kW / 10 kW peak |
| Supply voltage | 3-phase AC 400 V |
| DC link voltage | 600 V DC |
| Cooling | Internal/external cooling |
| Typical application | SIMODRIVE 611 drive groups on CNC machine tools |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $278/yr+3 yrs → 5 total $247/yr+5 yrs → 7 total $185/yrBEST VALUE+8 yrs → 10 total $139/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Siemens 6SN1146-1AB00-0BA1 is a SIMODRIVE 611 unregulated infeed module (UE) rated 5 kW / 10 kW peak. It rectifies the 3-phase 400 V supply to the 600 V DC link that feeds the power modules of the drive group; braking energy is dissipated in a pulsed resistor rather than returned to the mains. The infeed module is the first module in every SIMODRIVE 611 drive group and is a standard service part on SINUMERIK-controlled CNC machine tools.
Technical Specifications
Series SIMODRIVE 611 Type Unregulated infeed module (UE) Power rating 5 kW / 10 kW peak Supply voltage 3-phase AC 400 V DC link voltage 600 V DC Cooling Internal/external cooling Typical application SIMODRIVE 611 drive groups on CNC machine tools -
Part Number Breakdown
Part number reference — 6SN1146-1AB00-0BA1
SIMODRIVE 611 INFEED MODULE, 5/10 KW, UNREGULATED, WITH INTERNAL/EXT. COOLING
Official Siemens catalog description.
Specifications
designation UI module 5 kW (internal/external cooling) moduleType UI (unregulated) infeed module ratedPowerKw 5 s6PowerKw 6.5 peakPowerKw 10 ratedInputCurrentA 12 pulsedResistorContinuousPowerKw 0.2 pulsedResistorPeakPowerKw 10 pulsedResistorMaxEnergyKws 13.5 maxConnectionCrossSectionMm2 6 moduleWidthMm 50 cooling internal/external, non-ventilated efficiency 0.98 weightKg 6.5 Source: Siemens catalog sios-103471998-pju.pdf.
