Siemens 6SN1145-1BA01-0BA0
SKU: 6SN1145-1BA01-0BA0-R
We have 1 in stock
Estimated delivery: September 3rd - September 5th
Order for next-day shipment.
- Regular price
-
$2,224.00
- Sale price
- $2,224.00
IAC Certified Refurbished
$2,224
1 in stock
Ships today
Description
The Siemens 6SN1145-1BA01-0BA0 is a SIMODRIVE 611 infeed/regenerative feedback module (I/R) rated 16 kW / 21 kW peak. It rectifies the 3-phase 400 V supply to a stabilized 600 V DC link for the drive group's power modules and returns braking energy to the mains (regenerative feedback). It also generates the electronics supply for the module lineup. The infeed module is the first module in every SIMODRIVE 611 drive group and is a standard service part on SINUMERIK-controlled CNC machine tools.
Technical Specifications
| Series | SIMODRIVE 611 |
| Type | Infeed/regenerative feedback module (I/R) |
| Power rating | 16 kW / 21 kW peak |
| Supply voltage | 3-phase AC 400 V |
| DC link voltage | 600 V DC, closed-loop stabilized |
| Cooling | Internal cooling |
| Mains contactor | Integrated, with break (NC) contact |
| Typical application | SIMODRIVE 611 drive groups on CNC machine tools |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $334/yr+3 yrs → 5 total $297/yr+5 yrs → 7 total $222/yrBEST VALUE+8 yrs → 10 total $167/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Siemens 6SN1145-1BA01-0BA0 is a SIMODRIVE 611 infeed/regenerative feedback module (I/R) rated 16 kW / 21 kW peak. It rectifies the 3-phase 400 V supply to a stabilized 600 V DC link for the drive group's power modules and returns braking energy to the mains (regenerative feedback). It also generates the electronics supply for the module lineup. The infeed module is the first module in every SIMODRIVE 611 drive group and is a standard service part on SINUMERIK-controlled CNC machine tools.
Technical Specifications
Series SIMODRIVE 611 Type Infeed/regenerative feedback module (I/R) Power rating 16 kW / 21 kW peak Supply voltage 3-phase AC 400 V DC link voltage 600 V DC, closed-loop stabilized Cooling Internal cooling Mains contactor Integrated, with break (NC) contact Typical application SIMODRIVE 611 drive groups on CNC machine tools -
Part Number Breakdown
Part number reference — 6SN1145-1BA01-0BA0
SIMODRIVE 611 infeed/regenerative feedback module, 16/21 kW stabilized; mains protection with normally closed contact
Official Siemens catalog description.
Product family SIMODRIVE 611 Infeed Module Series SIMODRIVE 611 Type infeed module Fault codes (96)
Troubleshooting reference for the SIMODRIVE 611 digital Drive System:
- Fault 300007 — Axis %1 drive %2 not present or inactive
- Fault 300008 — Axis %1 drive %2 measuring circuit %3 is not available
- Fault 300009 — Axis %1 drive %2 measuring circuit %3 wrong measuring circuit type (type %4 used)
- Fault 300010 — Axis %1 drive %2 active without NC axis assignment
- Fault 300011 — Axis %1 drive %2 hardware version of spindle not supported
- Fault 300012 — Axis %1 drive %2 hardware version of control module not supported
- Fault 300020 — Drive %1 removed for diagnostics
- Fault 300100 — Drive power failure
- Fault 300101 — Bus communications failure
- Fault 300200 — Drive bus hardware fault
- Fault 300201 — Axis %1 drive %2 timeout during access, error location %3
- Fault 300202 — Axis %1 drive %2 CRC error, error location %3
See all 96 fault codes for this series →
