Siemens 6SN1124-1AB00-0CA2
SKU: 6SN1124-1AB00-0CA2-R
We have 1 in stock
Estimated delivery: September 3rd - September 5th
Order for next-day shipment.
- Regular price
-
$990.00
- Sale price
- $990.00
IAC Certified Refurbished
$990
1 in stock
Ships today
Description
The Siemens 6SN1124-1AB00-0CA2 is a SIMODRIVE 611 power module, 2-axis, rated 50 A per axis with external cooling. The power module contains the IGBT output stage of the drive: it receives DC link power from the SIMODRIVE 611 infeed module and, driven by the plugged-in control unit (611-D, 611 universal, or 611-A), supplies the motor. SIMODRIVE 611 power modules are core service parts on SINUMERIK-controlled CNC machine tools.
The 6SN1124 series is the externally cooled variant of the SIMODRIVE 611 power module range, with the heat sink projecting through the cabinet rear wall to dissipate losses outside the enclosure.
Technical Specifications
| Series | SIMODRIVE 611 |
| Type | Power module |
| Number of axes | 2 |
| Rated current | 50 A per axis |
| Cooling | External cooling |
| Rated motor currents | Feed = 18 A, main spindle = 24 A |
| DC link voltage | 600 V DC (from SIMODRIVE 611 infeed module) |
| Control unit | Accepts SIMODRIVE 611-D, 611 universal, or 611-A plug-in control units |
| Typical application | Feed and main spindle drives on CNC machine tools |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $149/yr+3 yrs → 5 total $132/yr+5 yrs → 7 total $99/yrBEST VALUE+8 yrs → 10 total $74/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Siemens 6SN1124-1AB00-0CA2 is a SIMODRIVE 611 power module, 2-axis, rated 50 A per axis with external cooling. The power module contains the IGBT output stage of the drive: it receives DC link power from the SIMODRIVE 611 infeed module and, driven by the plugged-in control unit (611-D, 611 universal, or 611-A), supplies the motor. SIMODRIVE 611 power modules are core service parts on SINUMERIK-controlled CNC machine tools.
The 6SN1124 series is the externally cooled variant of the SIMODRIVE 611 power module range, with the heat sink projecting through the cabinet rear wall to dissipate losses outside the enclosure.
Technical Specifications
Series SIMODRIVE 611 Type Power module Number of axes 2 Rated current 50 A per axis Cooling External cooling Rated motor currents Feed = 18 A, main spindle = 24 A DC link voltage 600 V DC (from SIMODRIVE 611 infeed module) Control unit Accepts SIMODRIVE 611-D, 611 universal, or 611-A plug-in control units Typical application Feed and main spindle drives on CNC machine tools -
Part Number Breakdown
Part number reference — 6SN1124-1AB00-0CA2
SIMODRIVE 611 POWER MODULE, 2-AXIS, EXTERNAL COOLING, MOTOR RATED CURRENT: FEED = 18 A MAIN SPINDEL = 24 A
Official Siemens catalog description.
Specifications
designation PM module, 2x50 A, 2-axis, external cooling moduleType power module, 2-axis ratedCurrentPerAxisSrmA 18 peakCurrentPerAxisSrmA 36 ratedCurrentPerAxisImA 24 s6CurrentPerAxisImA 32 peakCurrentPerAxisImA 32 minMotorCurrentA 3.6 transistorLimitCurrentPerAxisA 50 moduleWidthMm 100 weightKg 13.5 cooling external (fan) dcLinkVoltage 600/625 V DC regulated Source: Siemens catalog sios-103471998-pju.pdf.
