Siemens 6SN1118-0DJ23-0AA0
SKU: 6SN1118-0DJ23-0AA0-R
We have 35 in stock
Estimated delivery: September 2nd - September 4th
Order for next-day shipment.
- Regular price
-
$790.00
- Sale price
- $790.00
IAC Certified Refurbished
$790
35 in stock
Ships today
Description
The Siemens 6SN1118-0DJ23-0AA0 is a SIMODRIVE 611 digital high-performance closed-loop plug-in control unit for 1 axis with support for a direct measuring system. It mounts into a SIMODRIVE 611 power module and closes the position loop against a direct (linear/rotary) scale in addition to the motor encoder, under SINUMERIK CNC control. NC software 06.04.09 or later is required.
Technical Specifications
| Series | SIMODRIVE 611-D (digital) |
| Type | Closed-loop plug-in control unit, high performance |
| Number of axes | 1 |
| Measuring system | Motor encoder plus direct measuring system |
| Drive types | Feed drives and main spindle drives |
| Format | Plug-in unit for SIMODRIVE 611 power module |
| Software requirement | NC software 06.04.09 or later |
| Control system | SINUMERIK 840D / 810D digital CNC |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $119/yr+3 yrs → 5 total $105/yr+5 yrs → 7 total $79/yrBEST VALUE+8 yrs → 10 total $59/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Siemens 6SN1118-0DJ23-0AA0 is a SIMODRIVE 611 digital high-performance closed-loop plug-in control unit for 1 axis with support for a direct measuring system. It mounts into a SIMODRIVE 611 power module and closes the position loop against a direct (linear/rotary) scale in addition to the motor encoder, under SINUMERIK CNC control. NC software 06.04.09 or later is required.
Technical Specifications
Series SIMODRIVE 611-D (digital) Type Closed-loop plug-in control unit, high performance Number of axes 1 Measuring system Motor encoder plus direct measuring system Drive types Feed drives and main spindle drives Format Plug-in unit for SIMODRIVE 611 power module Software requirement NC software 06.04.09 or later Control system SINUMERIK 840D / 810D digital CNC -
Part Number Breakdown
Part number reference — 6SN1118-0DJ23-0AA0
SIMODRIVE 611 DIGITAL HIGH PERFORMANCE, DIRECT MEAS. SYSTEM 1 AXIS CLOSED-LOOP CONTROL PLUG-IN NC SOFTWARE, REQUIRED FROM 06.04.09
Official Siemens catalog description.
Product family SIMODRIVE 611 Control Unit Series SIMODRIVE 611 Type control unit Fault codes (96)
Troubleshooting reference for the SIMODRIVE 611 digital Drive System:
- Fault 300007 — Axis %1 drive %2 not present or inactive
- Fault 300008 — Axis %1 drive %2 measuring circuit %3 is not available
- Fault 300009 — Axis %1 drive %2 measuring circuit %3 wrong measuring circuit type (type %4 used)
- Fault 300010 — Axis %1 drive %2 active without NC axis assignment
- Fault 300011 — Axis %1 drive %2 hardware version of spindle not supported
- Fault 300012 — Axis %1 drive %2 hardware version of control module not supported
- Fault 300020 — Drive %1 removed for diagnostics
- Fault 300100 — Drive power failure
- Fault 300101 — Bus communications failure
- Fault 300200 — Drive bus hardware fault
- Fault 300201 — Axis %1 drive %2 timeout during access, error location %3
- Fault 300202 — Axis %1 drive %2 CRC error, error location %3
See all 96 fault codes for this series →
