Siemens 6ES7532-5HD00-0AB0
SKU: 6ES7532-5HD00-0AB0-FS
We have 9 in stock
Estimated delivery: August 28th - August 30th
Order for next-day shipment.
- Regular price
-
$997.00
- Sale price
- $997.00
New
$997
9 in stock
Ships today
Description
The Siemens 6ES7532-5HD00-0AB0 is a SIMATIC S7-1500 analog output module AQ 4xU/I ST (Standard) with four configurable voltage/current outputs for actuators such as control valves and drive setpoint inputs. It supports diagnostics and substitute values, plus safety-oriented shutdown of load groups up to SIL 2 (EN IEC 62061) and Category 2 / PL c (EN ISO 13849-1). Delivery includes infeed element, shield bracket, and shield terminal; the front connector is ordered separately.
Technical Specifications
| Series | SIMATIC S7-1500 |
| Type | Analog output module AQ 4xU/I ST |
| Channels | 4, in groups of 4 |
| Resolution | 16 bit |
| Accuracy | 0.3% |
| Output types | Voltage or current, configurable per channel |
| Diagnostics | Yes; substitute value behavior |
| Safe shutdown | Load groups up to SIL2 / Cat. 2, PL c |
| Included | Infeed element, shield bracket, shield terminal |
| Front connector | Screw or push-in, ordered separately |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $150/yr+3 yrs → 5 total $133/yr+5 yrs → 7 total $100/yrBEST VALUE+8 yrs → 10 total $75/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Siemens 6ES7532-5HD00-0AB0 is a SIMATIC S7-1500 analog output module AQ 4xU/I ST (Standard) with four configurable voltage/current outputs for actuators such as control valves and drive setpoint inputs. It supports diagnostics and substitute values, plus safety-oriented shutdown of load groups up to SIL 2 (EN IEC 62061) and Category 2 / PL c (EN ISO 13849-1). Delivery includes infeed element, shield bracket, and shield terminal; the front connector is ordered separately.
Technical Specifications
Series SIMATIC S7-1500 Type Analog output module AQ 4xU/I ST Channels 4, in groups of 4 Resolution 16 bit Accuracy 0.3% Output types Voltage or current, configurable per channel Diagnostics Yes; substitute value behavior Safe shutdown Load groups up to SIL2 / Cat. 2, PL c Included Infeed element, shield bracket, shield terminal Front connector Screw or push-in, ordered separately -
Part Number Breakdown
Part number reference — 6ES7532-5HD00-0AB0
SIMATIC S7-1500, Analog output module AQ 4xU/I ST, 16 bit resolution, Accuracy 0.3 RATE. 4 channels in groups of 4, diagnostics, substitute value incl. power supply element, shield bracket and shield terminal: Front connector (screw terminals or push-in) separately
Official Siemens catalog description.
