Omron E3A2-XCM4D
SKU: E3A2-XCM4D-FS
This product is not available for online purchase.
Use the Request a quote to get the pricing
Description
The Omron E3A2-XCM4D is a specialized receiver unit designed for through-beam photoelectric sensor systems, serving as the detector for long-range industrial applications. Working in tandem with a separate emitter, it triggers a control signal immediately upon beam interruption, utilizing Dark-ON logic to detect objects passing between the units. A key feature of this model is its standard M12 4-pin connector, which allows maintenance personnel to perform rapid, tool-free replacements without disrupting hardwired cabling. Although a legacy component, its rugged construction and 10-meter sensing range make it an enduring choice for retrofitting and maintaining established production lines.
- SENSOR AMPLIFIER
- FIBER-OPTIC
- LIGHT-ON/DARK-ON SELECTABLE
- 3 AMP RELAY OUTPUT
- ON-DELAY/OFF-DELAY INDEPENDENTLY ADJUSTABLE
- 0.1-5 SECOND RANGE
- 24-240 VAC / 12-240 VDC UNIVERSAL SUPPLY
-
Buying Options
-
Description
The Omron E3A2-XCM4D is a specialized receiver unit designed for through-beam photoelectric sensor systems, serving as the detector for long-range industrial applications. Working in tandem with a separate emitter, it triggers a control signal immediately upon beam interruption, utilizing Dark-ON logic to detect objects passing between the units. A key feature of this model is its standard M12 4-pin connector, which allows maintenance personnel to perform rapid, tool-free replacements without disrupting hardwired cabling. Although a legacy component, its rugged construction and 10-meter sensing range make it an enduring choice for retrofitting and maintaining established production lines.
- SENSOR AMPLIFIER
- FIBER-OPTIC
- LIGHT-ON/DARK-ON SELECTABLE
- 3 AMP RELAY OUTPUT
- ON-DELAY/OFF-DELAY INDEPENDENTLY ADJUSTABLE
- 0.1-5 SECOND RANGE
- 24-240 VAC / 12-240 VDC UNIVERSAL SUPPLY
-
Specifications
Omron E3A2-XCM4D Reference E3A2 Series ReceiverOmron
E3A2-XCM4DThe **E3A2-XCM4D** is the specialized receiver unit for Omron's heavy-duty through-beam photoelectric sensor system. Designed for long-distance detection in harsh industrial environments, it features a robust housing and an M12 connector ("M4" suffix) for rapid maintenance. As a "Dark-ON" configured detector, it triggers an output when the infrared beam from its partner emitter is interrupted by an object.
OMRON RCVRStableOutThrough-Beam Operation Principle
Emitter (L)Infrared Beam (10m Max)Receiver (D)Stable Light (Beam Clear)
Green LED ON. Output OFF (Dark-ON logic).
Light Interrupted (Blocked)
Orange LED ON. Output ON (Active).
M12 Connector Wiring
M12 Male (Face View)1234Pin Wire Color Function 1 Brown 10-30 VDC (+) 2 White Mode / N.C. 3 Blue 0 V (Ground) 4 Black Output Signal Technical Specifications
10 mSensing RangeDark-ONOperation ModeM124-Pin ConnectorIP66ProtectionStatus: Legacy Product. Recommended replacement: Omron E3Z Series.
-
