Honeywell Modutrol IV Motor, Non-Spring Return - M6294F1009-F/U

The Honeywell Modutrol IV Motor, Non-Spring Return is a high-performance motor with a torque rating of 300 in-lb, operating at 24V, and power consumption of 17 VA. With Floating Control and Linear 10K Feedback, this motor showcases versatility in automation and control functions.

This device stands out with an integral junction box that ensures NEMA 3 weather protection when mounted upright. Its design permits it to work with both normally open and normally closed valves and dampers. Noteworthy is its inclusive, electrically isolated feedback potentiometer that offers precise shaft position indication.

Consistent operation is maintained by the motor and its circuitry from a 24 VAC source. It features quick-connect terminals as standard, however a screw terminal adapter is optionally available. Adjusting to older interfaces is convenient as adapter brackets for matching shaft height of older motors exist.

In terms of functionality, these motors come with field-adjustable stroke, varying between 90 to 160 degrees. They also include integral auxiliary switches, available either factory-mounted or additionally field-installed. Valued across all models is the presence of dual shafts (slotted and tapped on both ends) and auxiliary switch cams, which contribute to its adaptability. Unfaltering torque is maintained throughout the entire voltage range.

Technical specifications highlight a power consumption of 17 VA, operating conditions from -40 F to 150 F (-40 C to 60 C), screw terminal electrical connections, a NEMA 3 housing, and the presence of 2 auxiliary switches.
