Beckhoff EL4004 New

Beckhoff EL4004

SKU: EL4004-FS

We have 7 in stock

Estimated delivery: June 9th - June 11th

Order for next-day shipment.

This product is not available for online purchase.

Use the Request a quote to get the pricing

$295.00
$295.00
New
$295
7 in stock
Ships today

Description

  • ETHERCAT TERMINAL
  • 4-CHANNEL
  • ANALOG OUTPUT
  • 0-10 V
  • 12 BIT RESOLUTION
  • 4 X 2-WIRE SYSTEM
  • -25 TO +60 DEGREES C
  • IP20
$295.00
$295.00
More payment options

Secure payment options

  • Eligible for next day delivery

    Orders placed before 4 PM ET ship same day for rapid replacement, minimizing downtime.

    More about shipping

  • 24 month warranty

    Twice the industry standard—full protection against defects for 2 full years.

    More about warranty

  • Multiple conditions available

    Multiple sourcing paths to help you control costs without compromising performance.

    More about warranty

  • Best catalog

    Large U.S. inventory and fast sourcing for Mitsubishi, Siemens, Schneider & more.

    Read More
  • Buying Options

    All products are covered by Industrial Automation Co.'s 2-Year Warranty.

    Condition SKU Price Warranty Availability Quantity Purchase
    New EL4004-FS $295.00 USD 2 Year Extended Warranty 7 In Stock in the United States!
  • Description
    • ETHERCAT TERMINAL
    • 4-CHANNEL
    • ANALOG OUTPUT
    • 0-10 V
    • 12 BIT RESOLUTION
    • 4 X 2-WIRE SYSTEM
    • -25 TO +60 DEGREES C
    • IP20
  • Specifications
    EtherCAT Terminal

    Beckhoff
    EL4004

    The **EL4004** is a 4-channel analog output terminal designed for the EtherCAT system. It converts digital 12-bit integer values from the automation controller into **0 to 10 V** signals. With high density in a 12mm housing, it serves as the interface for controlling actuators, frequency converters, and valve terminals.

    EL4004
    BECKHOFF
    Run
    Ch 1
    Ch 2
    Ch 3
    Ch 4
    0...10V
    1
    5
    2
    6
    3
    7
    4
    8

    Digital to Analog Conversion

    The EL4004 acts as a bridge between the digital logic of the PLC (TwinCAT) and the physical analog world. It takes a 12-bit number (0 to 4095) and translates it into a voltage level.

    EtherCAT Digital Data
    EL4004 DAC
    Output 0...10 V
    2.5V
    5.0V
    7.5V
    10V
    Resolution: 12-Bit

    2-Wire Connection Technique

    EL4004
    1 (AO 1)
    +
    5 (0V)
    -
    Actuator 0-10V Control Input

    Each of the 4 channels has a Signal Pin (1, 2, 3, 4) and a Ground Pin (5, 6, 7, 8). The ground (0V) is internally connected to the power contact.

    Technical Data

    Outputs 4 Single-ended
    Signal Voltage 0...10 V
    Resolution 12 Bit 4096 Steps
    Conversion Time ~140 µs
    Isolation 1500 V E-bus/Field
    Load > 5 kΩ Short-circuit proof
    Width 12 mm
    Weight 60 g
    Reference: Beckhoff EL4004 Data Sheet
