FANUC A06B-1513-B100#0402 AC Spindle Motor
SKU: A06B-1513-B100#0402
This product is not available for online purchase.
Use the Request a quote to get the pricing
Description
The A06B-1513-B100#0402 is a high-performance AC spindle model designed for diverse industrial applications, characterized by exceptional reliability and precision. As a part of the renowned A06B-1513 product series, it features a taper shaft and a remarkable maximum rotational speed of 7000HV, making it ideal for high-speed machining tasks. Its flange-mounted design allows for straightforward installation, while the slick shaft ensures reduced friction and enhanced durability. Additionally, this spindle supports rear mounting configurations for flexibility in machine layouts and is compatible with incremental encoders for precise positional control. Please note, availability is variable, and while core exchange is an option, repairs are not offered at this time.
-
Buying Options
-
Description
The A06B-1513-B100#0402 is a high-performance AC spindle model designed for diverse industrial applications, characterized by exceptional reliability and precision. As a part of the renowned A06B-1513 product series, it features a taper shaft and a remarkable maximum rotational speed of 7000HV, making it ideal for high-speed machining tasks. Its flange-mounted design allows for straightforward installation, while the slick shaft ensures reduced friction and enhanced durability. Additionally, this spindle supports rear mounting configurations for flexibility in machine layouts and is compatible with incremental encoders for precise positional control. Please note, availability is variable, and while core exchange is an option, repairs are not offered at this time.
-
Part Number Breakdown
Part number breakdown — A06B-1513-B100#0402
FANUC AC Spindle Motor αiI HV series (400-V class, A06B-15xx)
Motor model 1513αiI 40/6000HV AC Spindle Motor Specifications
kwCont S1 CONT 37 kW @ 1500-4000 min-1 / 26 kW @ 6000 min-1 kw30min S2 30 min, S3 60%: 45 kW @ 1500-4000 min-1 / 30 kW @ 6000 min-1 speedRangeRpm 1500-4000 (constant-power range) / 6000 max min-1 ampS2S3MaxA 99 motorInputV 316-460 V ampInputV 400-480 V (amplifier input) freq 50/60 Hz phase 3 poles 4 windingConnection Δ (delta) powerFactorPct 85 insulationClass H ipRating IP54 ambTempC 0-40 C manualNo B-65272EN Alarm codes (80)
Motor-related alarms are displayed by the connected amplifier / CNC. Full troubleshooting reference for this spindle motor:
- Alarm A — Program ROM error
- Alarm A1 — Program ROM error
- Alarm A2 — Program ROM error
- Alarm 01 — Motor overheat
- Alarm 02 — Excessive velocity error
- Alarm 03 — DC link fuse blown
- Alarm 04 — Open phase in the converter main power supply
- Alarm 06 — Temperature sensor disconnected
- Alarm 07 — Overspeed
- Alarm 09 — Main circuit overload/IPM overheat
- Alarm 11 — Converter: DC link overvoltage
- Alarm 12 — DC link overcurrent/IPM alarm
See all 80 alarm codes for this series →
