Siemens 6SN1118-0DJ21-0AA2
SKU: 6SN1118-0DJ21-0AA2-R
We have 4 in stock
Estimated delivery: September 1st - September 3rd
Order for next-day shipment.
- Regular price
-
$590.00
- Sale price
- $590.00
IAC Certified Refurbished
$590
4 in stock
Ships today
Description
The Siemens 6SN1118-0DJ21-0AA2 is a SIMODRIVE 611 digital high-performance closed-loop control unit for 1 axis with sin/cos 1 Vpp encoder interface. It is the later hardware revision of the 6SN1118-0DJ21 control unit and mounts as a plug-in unit into a SIMODRIVE 611 power module, providing digital current, speed, and position control for feed and main spindle drives under SINUMERIK 840D/810D CNC control.
Technical Specifications
| Series | SIMODRIVE 611-D (digital) |
| Type | Closed-loop plug-in control unit, high performance |
| Number of axes | 1 |
| Encoder interface | Sin/cos 1 Vpp |
| Drive types | Feed drives and main spindle drives |
| Format | Plug-in unit for SIMODRIVE 611 power module |
| Software requirement | NC software 06.04.09 or later |
| Control system | SINUMERIK 840D / 810D digital CNC |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $89/yr+3 yrs → 5 total $79/yr+5 yrs → 7 total $59/yrBEST VALUE+8 yrs → 10 total $44/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Siemens 6SN1118-0DJ21-0AA2 is a SIMODRIVE 611 digital high-performance closed-loop control unit for 1 axis with sin/cos 1 Vpp encoder interface. It is the later hardware revision of the 6SN1118-0DJ21 control unit and mounts as a plug-in unit into a SIMODRIVE 611 power module, providing digital current, speed, and position control for feed and main spindle drives under SINUMERIK 840D/810D CNC control.
Technical Specifications
Series SIMODRIVE 611-D (digital) Type Closed-loop plug-in control unit, high performance Number of axes 1 Encoder interface Sin/cos 1 Vpp Drive types Feed drives and main spindle drives Format Plug-in unit for SIMODRIVE 611 power module Software requirement NC software 06.04.09 or later Control system SINUMERIK 840D / 810D digital CNC -
Part Number Breakdown
Part number reference — 6SN1118-0DJ21-0AA2
SIMODRIVE 611 DIGITAL CONTROL LOOP BLOCK HIGH PERFORMANCE, 1 AXIS SIN/COS 1 VPP
Official Siemens catalog description.
Product family SIMODRIVE 611 Control Unit Series SIMODRIVE 611 Type control unit Fault codes (96)
Troubleshooting reference for the SIMODRIVE 611 digital Drive System:
- Fault 300007 — Axis %1 drive %2 not present or inactive
- Fault 300008 — Axis %1 drive %2 measuring circuit %3 is not available
- Fault 300009 — Axis %1 drive %2 measuring circuit %3 wrong measuring circuit type (type %4 used)
- Fault 300010 — Axis %1 drive %2 active without NC axis assignment
- Fault 300011 — Axis %1 drive %2 hardware version of spindle not supported
- Fault 300012 — Axis %1 drive %2 hardware version of control module not supported
- Fault 300020 — Drive %1 removed for diagnostics
- Fault 300100 — Drive power failure
- Fault 300101 — Bus communications failure
- Fault 300200 — Drive bus hardware fault
- Fault 300201 — Axis %1 drive %2 timeout during access, error location %3
- Fault 300202 — Axis %1 drive %2 CRC error, error location %3
See all 96 fault codes for this series →
