Siemens 6SN1118-0DG23-0AA1
SKU: 6SN1118-0DG23-0AA1-R
We have 27 in stock
Estimated delivery: September 1st - September 3rd
Order for next-day shipment.
- Regular price
-
$295.00
- Sale price
- $295.00
IAC Certified Refurbished
$295
27 in stock
Ships today
Description
The Siemens 6SN1118-0DG23-0AA1 is a SIMODRIVE 611-D closed-loop plug-in performance control unit for 1 axis of digital feed or main spindle drive, with direct measuring system support. It mounts into a SIMODRIVE 611 power module and operates under SINUMERIK 840D/810D CNC control on machine tools.
This part number has been discontinued by the manufacturer; Industrial Automation Co supplies it as a service spare for installed SIMODRIVE 611 systems.
Technical Specifications
| Series | SIMODRIVE 611-D (digital) |
| Type | Closed-loop plug-in performance control unit |
| Number of axes | 1 |
| Drive types | Feed drives and main spindle drives |
| Measuring system | Motor encoder plus direct measuring system |
| Format | Plug-in unit for SIMODRIVE 611 power module |
| Lifecycle | Discontinued by manufacturer |
| Control system | SINUMERIK 840D / 810D digital CNC |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $44/yr+3 yrs → 5 total $39/yr+5 yrs → 7 total $30/yrBEST VALUE+8 yrs → 10 total $22/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Siemens 6SN1118-0DG23-0AA1 is a SIMODRIVE 611-D closed-loop plug-in performance control unit for 1 axis of digital feed or main spindle drive, with direct measuring system support. It mounts into a SIMODRIVE 611 power module and operates under SINUMERIK 840D/810D CNC control on machine tools.
This part number has been discontinued by the manufacturer; Industrial Automation Co supplies it as a service spare for installed SIMODRIVE 611 systems.
Technical Specifications
Series SIMODRIVE 611-D (digital) Type Closed-loop plug-in performance control unit Number of axes 1 Drive types Feed drives and main spindle drives Measuring system Motor encoder plus direct measuring system Format Plug-in unit for SIMODRIVE 611 power module Lifecycle Discontinued by manufacturer Control system SINUMERIK 840D / 810D digital CNC -
Part Number Breakdown
Part number reference — 6SN1118-0DG23-0AA1
SIMODRIVE 611-D CLOSED-LOOP PLUG-IN PERFORMANCE CONTROL UNIT,1 AXIS,FOR DIGITAL DRIVES,FEED+MAIN SPINDLE DRIVES WITH DIRECT MEASURING SYSTEM, VOLTAGE SIGNALS
Official Siemens catalog description.
Product family SIMODRIVE 611 Control Unit Series SIMODRIVE 611 Type control unit Fault codes (96)
Troubleshooting reference for the SIMODRIVE 611 digital Drive System:
- Fault 300007 — Axis %1 drive %2 not present or inactive
- Fault 300008 — Axis %1 drive %2 measuring circuit %3 is not available
- Fault 300009 — Axis %1 drive %2 measuring circuit %3 wrong measuring circuit type (type %4 used)
- Fault 300010 — Axis %1 drive %2 active without NC axis assignment
- Fault 300011 — Axis %1 drive %2 hardware version of spindle not supported
- Fault 300012 — Axis %1 drive %2 hardware version of control module not supported
- Fault 300020 — Drive %1 removed for diagnostics
- Fault 300100 — Drive power failure
- Fault 300101 — Bus communications failure
- Fault 300200 — Drive bus hardware fault
- Fault 300201 — Axis %1 drive %2 timeout during access, error location %3
- Fault 300202 — Axis %1 drive %2 CRC error, error location %3
See all 96 fault codes for this series →
