Siemens 6SL3130-7TE31-2AA3

Siemens 6SL3130-7TE31-2AA3

The SINAMICS S120 drive system for high-performance industrial applications includes the Siemens 6SL3130-7TE31-2AA3 Active Line Module. This module produces 120 kW (150 HP) at 380€€œ480 V 3 AC. Advanced energy management and reliable performance make it suited for industrial situations.

Technical Specifications:

The Siemens 6SL3130-7TE31-2AA3 offers a line frequency of 47 to 63 Hz and a line connection voltage of 380 to 480 V 3 AC ± 10%. The total power factor stays at 1.0. However, entering a reactive current setpoint can modify the active mode power factor. The smart mode has a basic power factor of over 0.96 and a total power factor between 0.65 and 0.90.

The DC link voltage is regulated in active mode and can be modified independently from the line voltage. Factory settings are 600 V for 380 to 400 V 3 AC and 625 V for 400 to 415 V 3 AC. At 416 to 480 V 3 AC, smart mode sets the DC link voltage at 1.35 times the line voltage. Electronics power supplies need 24 V DC with -15% to +20% tolerance.

The 6SL3130-7TE31-2AA3 meets strict radio interference regulations. Active interface module satisfies Category C3 to EN 61800-3 up to 350 m wire length. A basic line filter achieves Class A1 to EN 55011, Category C2 to EN 61800-3 up to 350 m, and Category C3 from 350 to 1000 m.

The Siemens 6SL3130-7TE31-2AA3's 0.98 efficiency ensures low energy loss. This module loses 2.20 kW with internal air cooling and 0.49€€œ1.71 kW with external air cooling. The cooling air needed is 0.144 m ³/s, and the sound pressure is kept below 75 dB for a quieter operation.

Design and Construction:

The Siemens 6SL3130-7TE31-2AA3 has a compact footprint of 300 mm wide, 380 mm high (629 mm with a fan), and 270 mm deep. It weighs 23 kg internally and 30.7 kg externally with air cooling. IP20 protects the module from environmental influences.

The module supports 244 A DC connection current at 600 V DC and 292 A for S6 duty (40%). At 380 V 3 AC, the input current is 192 A and can reach 292 A. The 24 V DC electronics power supply draws 2.5 A max. Operating energy loss is low because of the module's 0.98 efficiency. Power loss is 2.20 kW with internal air cooling and 0.49€€œ1.71 kW with external.

Installation and Connectivity:

The Siemens 6SL3130-7TE31-2AA3 has M8 screw studs (ring terminal ends) for line connections and a conductor cross-section range of 2.5 to 120 mm ². The housing has an M8 screw for the PE connection. Installation is flexible, with the module supporting shielded and unshielded cable lengths of 1000 and 1500 m, respectively.

A 24 V terminal adapter, DRIVE-CLiQ cable for the control unit, and blanking plugs for unused sockets are included with the module. It also has a connector to connect the 24 V DC busbar to nearby motor modules and multilingual warning signals.

Frequently Asked Questions:

What is the sound pressure level of the Siemens 6SL3130-7TE31-2AA3?

Below 75 dB, the Siemens 6SL3130-7TE31-2AA3 has minimal sound pressure. This makes operating quieter for noise-sensitive industrial environments.

What type of cooling system does the Siemens 6SL3130-7TE31-2AA3 use?

An incorporated fan enhances internal air conditioning in the Siemens 6SL3130-7TE31-2AA3. This optimizes performance and longevity in harsh industrial conditions.

What are the dimensions of the Siemens 6SL3130-7TE31-2AA3?

The Siemens 6SL3130-7TE31-2AA3 has dimensions of 300 mm width, 380 mm height (or 629 mm including the fan), and 270 mm depth. The model is designed to accommodate various industrial applications with its compact yet robust build.

Product Specifications Table:
