Schneider Electric MP63H2-3P-6300A
SKU: MP63H2-3P-6300A-FS
This product is not available for online purchase.
Use the Request a quote to get the pricing
Description
This Schneider Electric (Merlin Gerin) MP63H2-3P-6300A Masterpact insulated case circuit breaker carries ratings of 6300 A, 3-pole, 600 VAC. It provides 125kA@480V interrupting rating with solid state protection.
Factory specification: insulated case circuit breaker, Masterpact, 6300A frame, includes 6300A sensor rating with 6300A rating plug, 3P, 3PH, 600V, 125kA@480V, accepts the following programmer/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP, Solid State electronic, insulated case circuit breakers.
MP63H2-3P-6300A Technical Specifications
| Manufacturer | Schneider Electric (Merlin Gerin) |
| Series | Masterpact |
| Type | Insulated Case Circuit Breaker |
| Voltage | 600 V |
| Amperage | 6300 A |
| Poles | 3 |
| Phase | 3 |
| AIC Rating | 125kA@480V |
| Protection | Solid State |
The MP63H2-3P-6300A is available from Industrial Automation Co. in New and IAC Certified Refurbished condition. Contact our sales team for current availability, pricing, and lead time.
-
Buying Options
-
Description
This Schneider Electric (Merlin Gerin) MP63H2-3P-6300A Masterpact insulated case circuit breaker carries ratings of 6300 A, 3-pole, 600 VAC. It provides 125kA@480V interrupting rating with solid state protection.
Factory specification: insulated case circuit breaker, Masterpact, 6300A frame, includes 6300A sensor rating with 6300A rating plug, 3P, 3PH, 600V, 125kA@480V, accepts the following programmer/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP, Solid State electronic, insulated case circuit breakers.
MP63H2-3P-6300A Technical Specifications
Manufacturer Schneider Electric (Merlin Gerin) Series Masterpact Type Insulated Case Circuit Breaker Voltage 600 V Amperage 6300 A Poles 3 Phase 3 AIC Rating 125kA@480V Protection Solid State The MP63H2-3P-6300A is available from Industrial Automation Co. in New and IAC Certified Refurbished condition. Contact our sales team for current availability, pricing, and lead time.
-
