Fuji Electric DB7.5-2
SKU: DB7.5-2
Tenemos 19 en stock
Entrega estimada: August 30th - September 1st
Pida ahora para envío al día siguiente.
- Precio habitual
-
$ 6,636.00
- Precio de oferta
- $ 6,636.00
Default Title
$ 6,636
19 en stock
Se envía hoy
Description
The Fuji Electric DB7.5-2 is a dynamic braking resistor sized for 7.5 kW (10 HP) Fuji Electric variable frequency drives on 200V class supplies. It is the matching external braking resistor for FRENIC series drives, used together with the drive's built-in braking transistor or an external braking unit to absorb regenerative energy during deceleration.
When a VFD decelerates a motor, the motor acts as a generator and returns energy to the drive's DC bus. Without a braking resistor this regenerative energy raises the bus voltage and trips an overvoltage fault. The DB7.5-2 dissipates that energy as heat, enabling fast, repeatable, controlled deceleration in hoists, cranes, centrifuges, high-inertia fans and pumps, and winding applications. Install in a well-ventilated location; the resistor generates significant heat during braking cycles. Genuine Fuji Electric OEM accessory.
Technical Specifications
| Product type | Dynamic braking resistor |
| Matched drive capacity | 7.5 kW (10 HP) |
| Voltage class | 200V class |
| Compatible drives | Fuji Electric FRENIC series VFDs |
| Function | Dissipates regenerative braking energy as heat |
| Installation | External mount, ventilated location required |
| Manufacturer | Fuji Electric |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $995/yr+3 yrs → 5 total $885/yr+5 yrs → 7 total $664/yrBEST VALUE+8 yrs → 10 total $498/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Fuji Electric DB7.5-2 is a dynamic braking resistor sized for 7.5 kW (10 HP) Fuji Electric variable frequency drives on 200V class supplies. It is the matching external braking resistor for FRENIC series drives, used together with the drive's built-in braking transistor or an external braking unit to absorb regenerative energy during deceleration.
When a VFD decelerates a motor, the motor acts as a generator and returns energy to the drive's DC bus. Without a braking resistor this regenerative energy raises the bus voltage and trips an overvoltage fault. The DB7.5-2 dissipates that energy as heat, enabling fast, repeatable, controlled deceleration in hoists, cranes, centrifuges, high-inertia fans and pumps, and winding applications. Install in a well-ventilated location; the resistor generates significant heat during braking cycles. Genuine Fuji Electric OEM accessory.
Technical Specifications
Product type Dynamic braking resistor Matched drive capacity 7.5 kW (10 HP) Voltage class 200V class Compatible drives Fuji Electric FRENIC series VFDs Function Dissipates regenerative braking energy as heat Installation External mount, ventilated location required Manufacturer Fuji Electric -
