Siemens 6GK1901-0DB20-6AA0
SKU: 6GK1901-0DB20-6AA0-FS
We have 1 in stock
Estimated delivery: September 24th - September 26th
Order for next-day shipment.
- Regular price
-
$87.18
- Sale price
- $87.18
New
$87.18
1 in stock
Ships today
IAC Certified Refurbished
Available
Request a quote
New Open Box
Available
Request a quote
Description
The Siemens 6GK1901-0DB20-6AA0 is an Industrial Ethernet FastConnect M12 plug PRO, a field-assembly 2x2 M12 connector with a rugged metal enclosure and D-coded contacts. The FastConnect insulation displacement method allows the connector to be fitted to Industrial Ethernet cable in the field without special stripping of individual wires. With its axial cable outlet it is used for IP65/IP67 cabling of devices such as SCALANCE X208 PRO switches and ET 200 PRO PROFINET stations.
Technical Specifications
| Product family | Industrial Ethernet FastConnect |
| Type | M12 plug PRO, 2x2 |
| Coding | D-coded |
| Connection method | FastConnect insulation displacement |
| Cable outlet | Axial |
| Enclosure | Rugged metal |
| Typical use | SCALANCE X208 PRO, ET 200 PRO PN |
| Part number | 6GK1901-0DB20-6AA0 |
-
Buying Options
-
Description
The Siemens 6GK1901-0DB20-6AA0 is an Industrial Ethernet FastConnect M12 plug PRO, a field-assembly 2x2 M12 connector with a rugged metal enclosure and D-coded contacts. The FastConnect insulation displacement method allows the connector to be fitted to Industrial Ethernet cable in the field without special stripping of individual wires. With its axial cable outlet it is used for IP65/IP67 cabling of devices such as SCALANCE X208 PRO switches and ET 200 PRO PROFINET stations.
Technical Specifications
Product family Industrial Ethernet FastConnect Type M12 plug PRO, 2x2 Coding D-coded Connection method FastConnect insulation displacement Cable outlet Axial Enclosure Rugged metal Typical use SCALANCE X208 PRO, ET 200 PRO PN Part number 6GK1901-0DB20-6AA0 -
Part Number Breakdown
Part number reference — 6GK1901-0DB20-6AA0
Industrial Ethernet FastConnect M12 plug PRO 2x2 M12 plug-in connector with rugged metal enclosure and FC connection method, with axial cable outlet (D-coded) 1 pack=1 unit for SCALANCE X208 PRO and ET 200 PRO PN
Official Siemens catalog description.
Product family Industrial Ethernet FastConnect Connectors (IE FC RJ45 / M12 Plug) Series SIMATIC NET Type connector Questions or need a quote? Call 877-727-8757 or email sales@iac.us.com.
-
