AMK KEN 20-F
SKU: KEN 20-F
This product is not available for online purchase.
Use the Request a quote to get the pricing
Description
The KEN 20-F is a higher-capacity power supply module with a rated input voltage of 3 x 400...480 V AC ±10% at 47–63 Hz. It delivers a rated output power of 20 kW, peaking at 40 kW for up to 60 seconds. The module achieves an efficiency of approximately 99% and uses forced air cooling. Unlike the KEN 5-F and KEN 10-F, the KEN 20-F supports regenerative feedback and accommodates an optional external bleed resistor with a minimum resistance of 20 Ω. Protective functions cover mains failure, overcurrent, and overtemperature scenarios. The module weighs around 4.2 kg and has a width of 86 mm.
-
Buying Options
-
Description
The KEN 20-F is a higher-capacity power supply module with a rated input voltage of 3 x 400...480 V AC ±10% at 47–63 Hz. It delivers a rated output power of 20 kW, peaking at 40 kW for up to 60 seconds. The module achieves an efficiency of approximately 99% and uses forced air cooling. Unlike the KEN 5-F and KEN 10-F, the KEN 20-F supports regenerative feedback and accommodates an optional external bleed resistor with a minimum resistance of 20 Ω. Protective functions cover mains failure, overcurrent, and overtemperature scenarios. The module weighs around 4.2 kg and has a width of 86 mm.
-
