AMK KE 10
SKU: KE 10
This product is not available for online purchase.
Use the Request a quote to get the pricing
Description
The KE 10 is a compact power supply module designed for servo drive systems. It operates with an input voltage of 3 x 400–480 V AC at 47–63 Hz and an input current of 15 A. The module delivers an output power of 10 kW, with a maximum output of 20 kW for up to 60 seconds. It features an efficiency of approximately 99% and includes an integrated braking transistor. An external brake resistor with a minimum resistance of 22 Ω can be connected. Protective functions encompass line overcurrent (I²t), short circuit, and excess temperature monitoring. The KE 10 has a module width of 85 mm and weighs approximately 4.2 kg.
-
Buying Options
-
Description
The KE 10 is a compact power supply module designed for servo drive systems. It operates with an input voltage of 3 x 400–480 V AC at 47–63 Hz and an input current of 15 A. The module delivers an output power of 10 kW, with a maximum output of 20 kW for up to 60 seconds. It features an efficiency of approximately 99% and includes an integrated braking transistor. An external brake resistor with a minimum resistance of 22 Ω can be connected. Protective functions encompass line overcurrent (I²t), short circuit, and excess temperature monitoring. The KE 10 has a module width of 85 mm and weighs approximately 4.2 kg.
-
