Siemens 6ES7155-6AU01-0CN0
SKU: 6ES7155-6AU01-0CN0-FS
Low stock
Estimated delivery: October 15th - October 19th
Order for next-day shipment.
- Regular price
- $1,264.08
- Sale price
- $1,264.08
New
$1,264.08
Low stock
New Open Box
Call for Availability
Request a quote
Description
The Siemens 6ES7155-6AU01-0CN0 is a SIMATIC IM 155-6 PN/2 High Feature interface module for the ET 200SP distributed I/O system. It provides one BusAdapter slot for the PROFINET connection and supports up to 64 I/O modules plus 16 ET 200AL modules, S2 system redundancy, multi hot swap, and isochronous mode down to 0.25 ms. Optional PROFINET strain relief can be fitted, and the server module is included.
The High Feature station head targets large stations, redundant controller architectures, and high-speed synchronized I/O.
Technical Specifications
| Manufacturer | Siemens |
| Series | SIMATIC ET 200SP |
| Product Type | IM 155-6 PN/2 High Feature PROFINET interface module |
| Max. I/O Modules | 64 ET 200SP modules + 16 ET 200AL modules |
| Communication | PROFINET IO device, 1 BusAdapter slot |
| System Redundancy | S2 |
| Isochronous Mode | Yes, down to 0.25 ms |
| Hot Swap | Multi hot swap |
| Included | Server module |
| Supply Voltage | 24 V DC |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $190/yr+3 yrs → 5 total $169/yr+5 yrs → 7 total $126/yrBEST VALUE+8 yrs → 10 total $95/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Siemens 6ES7155-6AU01-0CN0 is a SIMATIC IM 155-6 PN/2 High Feature interface module for the ET 200SP distributed I/O system. It provides one BusAdapter slot for the PROFINET connection and supports up to 64 I/O modules plus 16 ET 200AL modules, S2 system redundancy, multi hot swap, and isochronous mode down to 0.25 ms. Optional PROFINET strain relief can be fitted, and the server module is included.
The High Feature station head targets large stations, redundant controller architectures, and high-speed synchronized I/O.
Technical Specifications
Manufacturer Siemens Series SIMATIC ET 200SP Product Type IM 155-6 PN/2 High Feature PROFINET interface module Max. I/O Modules 64 ET 200SP modules + 16 ET 200AL modules Communication PROFINET IO device, 1 BusAdapter slot System Redundancy S2 Isochronous Mode Yes, down to 0.25 ms Hot Swap Multi hot swap Included Server module Supply Voltage 24 V DC -
Part Number Breakdown
Part number reference — 6ES7155-6AU01-0CN0
SIMATIC ET 200SP, PROFINET 2-port interface module IM155-6PN/2 High Feature, 1 slot for SIMATIC BusAdapter, max. 64 Periphery modules and 16 ET 200AL modules, S2 redundancy, Multi Hot swapping, 0,25ms isochronous mode, inclusive server module
Official Siemens catalog description.
Product family SIMATIC ET 200MP IM 155-5 PN Interface Module (PROFINET IO-Device) Series SIMATIC ET 200MP Type communication module Questions or need a quote? Call 877-727-8757 or email sales@iac.us.com.
-
