Allen-Bradley 1756-IF16H
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice‚ here.
- 1756IF16H
- ANALOG INPUT MODULE
- CONTROLLOGIX
- 16 POINT
- ** HART COMMS **
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
Introduction
The Allen-Bradley 1756-IF16H serves as a HART Analog Input Module, showcasing Rockwell Automation's dedication to seamless industrial automation. This module is designed to interface with 16 differential inputs, efficiently converting and scaling them for digital processing. Compatible with the ControlLogix series, it sets the standard for robust and reliable signal processing in complex industrial settings.
Technical Specifications for Allen-Bradley 1756-IF16H
The 1756-IF16H supports a diverse range of input voltage from 0-20 or 4-20 milliamps, ensuring flexibility in accommodating various sensor outputs. With a resolution range between 16-21 bits, it boasts precise measurement capabilities. Equipped with overvoltage protection of up to 8 Volts DC and an isolation voltage of 50 Volts continuous, the module ensures robust protection and longevity of operation.
Setup and Operating Climate Conditions
This module operates efficiently within an open enclosure, indicating its reliance on well-ventilated environments to maintain optimal performance. The removable terminal blocks 1756-TBCH and 1756-TBS6H facilitate easy installation and maintenance. Recommended to use with RSLogix 5000 Software Version 8.02.00 or later, it integrates seamlessly into existing setups to enhance operational efficiency and reliability.
Components and Configuration
Included in the module are essential components for swift integration and setup. The removable terminal blocks simplify connection processes, enabling quick setup and modifications as needed. Compatibility with RSLogix 5000 software extends its usability, allowing for straightforward programming and configuration adjustments to meet diverse application requirements.
Enhanced Protective Features
Designed with the rigor of industrial environments in mind, the 1756-IF16H is furnished with advanced protective measures. These include overvoltage and continuous isolation voltage protection, safeguarding against electrical anomalies that could potentially impair module performance or cause downtime.
Seize Your Efficient Solution
Embrace enhanced operational efficiency with the Allen-Bradley 1756-IF16H. Order yours today and unlock the potential of reliable, precise analog signal processing.
